Lexus GS III facelift (2007-2011) defog relay Wiring diagrams
This page contains all the electrical diagrams for the component. defog relay, in which he is found in the car Lexus GS III facelift (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram defog relay (1 of 3)
A/C COMPRESSOR
AIR FUEL INJECTOR RATIO DRIVER SENSOR (EDU) (BANK 2 SHIELD SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
BLK WIRE
BLOWER MOTOR
BRN WIRE
CANISTER PUMP MODULE
CRANKSHAFT SPILL POSITION CONTROL SENSOR VALVE SHIELD SHIELD
DATA LINK CONNECTOR 3
DEFOG RELAY
DISTANCE CONTROL ECU
ENGINE CONTROL MODULE
ENGINE ENGINE IGNITION CONTROL CONTROL COIL 5 MODULE MODULE
ENGINE OIL LEVEL SENSOR
ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
FAN MAIN RELAY
GRN WIRE
GRY WIRE
IGNITION
IGNITION COIL 2
IGNITION COIL 3 COIL 1
IGNITION IGNITION COIL 6 COIL 4
JUNCTION CONNECTOR
KNOCK CONTROL SENSOR (BANK 1, 2) SHIELDS
LEFT CENTER J/B (BEHIND
MILLIMETER WAVE RADAR SENSOR
NCA WIRE
NOISE FILTER
NOISE FILTER (GHOST BUSTER)
POWER STEERING ECU
RIGHT CENTER J/B (BEHIND
SKID CONTROL ECU
SPIRAL CABLE
STARTER RELAY
STEERING CONTROL ECU
TRANSMISSION CONTROL SWITCH
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 8) -> DEFOG RELAY
Wiring diagram defog relay (2 of 3)
BLK WIRE
BLOWER MOTOR
BLU WIRE
BRN WIRE
CONVERTER (ACTIVE STABILIZER)
COOLING FAN ECU
DEFOG RELAY
ENGINE HOOD COURTESY SWITCH
EXCEPT MARK LEVINSON MARK LEVINSON
FAN MAIN RELAY
FRONT STABILIZER CONTROL ECU
FRONT STABILIZER CONTROL ECU SHIELD
FUEL INJECTOR 1 SHIELD
FUEL INJECTOR 2 SHIELD
FUEL INJECTOR 3 SHIELD
FUEL INJECTOR 4 SHIELD
FUEL INJECTOR 5 SHIELD
FUEL INJECTOR 6 SHIELD
LEFT HEADLAMP ASSEMBLY
LEFT RIGHT FRONT FRONT FOG LAMP FOG LAMP
NCA WIRE
NOISE FILTER
OIL PMP RELAY
POWER STEERING ECU
POWER STEERING MOTOR SHIELD
RADIO RECEIVER ASSEMBLY
REAR STABILIZER CONTROL ECU
REAR STABILIZER CONTROL ECU SHIELD
RIGHT HEADLAMP ASSEMBLY
SMOG VENTILATION SENSOR
STEERING CONTROL ECU
STEREO COMPONENT AMPLIFIER
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (7 of 7) -> DEFOG RELAY
Wiring diagram defog relay (3 of 3)
1 2 TX- TX+
10 9 TX- TX+
24 25 CANL CANH
9 10 TXM+ TXM-
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAIL CAIH GTX+ GTX-
COMPUTER DATA LINES SYSTEM
DEFOG FUSE
DEFOG RELAY
ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT)
ENGINE ROOM J/B 1 (RIGHT REAR OF ENGINE COMPT)
ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
GATEWAY ECU (BEHIND RIGHT SIDE OF DASH)
GRN/BLK WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT COWL SIDE J/B (BEHIND LEFT SIDE OF DASH)
LH-IG FUSE
LT BLU WIRE
LT GRN WIRE
MULTI-DISPLAY
NOISE FILTER
POWER SOURCE CONTROL ECU (BEHIND RIGHT SIDE OF DASH)
RADIO RECEIVER ASSEMBLY
RDEF
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER SWITCH
RELAY
RIGHT COWL SIDE J/B (BEHIND RIGHT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Rear defogger circuit -> DEFOG RELAY
