Lexus GS III facelift (2007-2011) crankshaft position sensor shield Wiring diagram
This page shows the only wiring diagram for the component.crankshaft position sensor shield, which is found in the car Lexus GS III facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram crankshaft position sensor shield (1 of 1)
ACCELERATOR POSITION SENSOR SHIELD
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BRN WIRE
CANISTER PUMP MODULE
CRANKSHAFT POSITION SENSOR SHIELD
DATA LINK CONNECTOR 3
DISTANCE CONTROL ECU
ENGINE CONTROL MODULE
ENGINE OIL LEVEL REFUELING SENSOR VALVE
ENGINE ROOM IGCT INV W/P J/B 1 (LEFT SIDE OF ENGINE COMPT) RELAY RELAY
FUEL TANK PRESSURE SENSOR
GRN WIRE
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
HEATED OXYGEN SENSOR (BANK 2 SENSOR 2) SHIELD
HYBRID VEHICLE CONTROL ECU
IGNITION COIL 2
IGNITION IGNITION COIL 4 COIL 6
IGNITION IGNITION IGNITION COIL 1 COIL 3 COIL 5
INJECTOR DRIVER SHIELD
J/C
KNOCK CONTROL SENSORS SHIELD
LEFT CENTER J/B (BEHIND
MILLIMETER WAVE RADAR SENSOR
NCA WIRE
RIGHT CENTER J/B (BEHIND RIGHT SIDE OF DASH)
SPILL CONTROL VALVE SHIELD
SPIRAL CABLE
TRANSMISSION CONTROL SWITCH
VIO/WHT WIRE
WATER PUMP COMPRESSOR MOTOR (A/C) MOTOR
WATER PUMP MOTOR (INVERTER)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Ground distribution circuit (2 of 7) -> CRANKSHAFT POSITION SENSOR SHIELD
