Lexus GS III (2004-2007) tail off auto head light control switch Wiring diagram
This page shows the only wiring diagram for the component.tail off auto head light control switch, which is found in the car Lexus GS III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail off auto head light control switch (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BODY ECU 2 (IN DRIVER SIDE J/B)
COMBINATION SWITCH
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
EB (AT MIDDLE OF LEFT INNER FENDER PANEL)
ENGINE ROOM R/B 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
H-LP CLN FUSE
HEAD
HEAD LP RELAY
HEADLIGHT CLEANER MOTOR (AT LEFT FRONT CORNER OF ENGINE COMPT, BEHIND HEADLIGHT)
HEADLIGHT CLEANER SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION CONNECTOR
JUNCTION CONNECTOR 10 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 6 (BEHIND LEFT KICK PANEL) IF
MAIN FUSE
MTR
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
TAIL OFF AUTO HEAD LIGHT CONTROL SWITCH
WASHER FUSE
WHT/BLK WIRE
Go to component -> Headlamp washer circuit -> TAIL OFF AUTO HEAD LIGHT CONTROL SWITCH
