Lexus GS III (2004-2007) stop- light noise filter wiring diagram
This page shows the only wiring diagram for the component.stop- light noise filter, which is found in the car Lexus GS III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
stop- light noise filter wiring diagram (1 of 1)
AUTO ANTENNA CONTROL RELAY, MOTOR (MARK LEVINSON) NAVIGATION ECU
BJ (AT LEFT REAR FLOOR PARTITION PANEL)
BK (AT LEFT REAR QUARTERPANEL)
BL (AT RIGHT REAR FLOOR PARTITION PANEL)
BLK WIRE
BM (AT RIGHT REAR QUARTERPANEL)
BRN WIRE
DRIVER'S POWER SEAT CONTROL SWITCH
DRIVER'S POWER SEAT FRONT VERTICAL POSITION SENSOR
DRIVER'S POWER SEAT RECLINE POSITION SENSOR
DRIVER'S SEAT LUMBAR SUPPORT CONTROL SWITCH
DRIVER'S SEAT- BACK HEATER
FRONT PASSENGER'S POWER SEAT CONTROL SWITCH
FRONT PASSENGER'S SEAT BACK HEATER
FRONT PASSENGER'S SEAT LUMBAR SUPPORT CONTROL SWITCH
FUEL LID OPENER MOTOR
FUEL PUMP CONTROL ECU
HIGH MOUNTED STOP LIGHT
JUNCTION CONNECTOR 20 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR 22 (ABOVE RIGHT REAR WHEELWELL)
JUNCTION CONNECTOR 23 (UNDER LEFT FRONT SEAT)
JUNCTION CONNECTOR 24 (UNDER RIGHT FRONT SEAT)
JUNCTION CONNECTOR 28 (RIGHT SIDE OF LUGGAGE COMPT)
LED
LEFT BUCKLE SWITCH
LEFT LICENSE PLATE LIGHT
LEFT REAR COMBINATION LIGHT
LEFT REAR DOOR ECU
LIGHT FAILURE SENSOR
LUGGAGE COMPARTMENT DOOR KEY UNLOCK SWITCH
POWER SEAT ECU
RIGHT BUCKLE SWITCH, SEAT BELT WARNING OCCUPANT DETECTION SENSOR
RIGHT LICENSE PLATE LIGHT
RIGHT REAR COMBINATION LIGHT
RIGHT REAR DOOR ECU
SPOILER
STOP- LIGHT NOISE FILTER
TELEPHONE TRANSCEIVER/ SPEAKER RELAY
W/ MEMORY
W/ REAR
W/O MEMORY
W/O REAR
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK CONTROL ECU
Go to component -> Ground distribution circuit (4 of 4) -> STOP- LIGHT NOISE FILTER
