Lexus GS III (2004-2007) steering pad switch (combination switch) Wiring diagrams
This page contains all the electrical diagrams for the component. steering pad switch (combination switch), in which he is found in the car Lexus GS III (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
steering pad switch (combination switch) wiring diagram (1 of 2)
2 1 +B
6 7 TRLY DBKL
A/C CONTROL ASSEMBLY (BEHIND CENTER OF DASH)
ANTI-LOCK BRAKES SYSTEM
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BODY ECU 2 (IN DRIVER SIDE J/B)
BRN/BLK WIRE
COMBINATION METER
DOOR LOCKS SYSTEM
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
ECU-IG FUSE
ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT, IN ECU BOX)
EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
EXTERIOR LIGHTS SYSTEM WARNING SYSTEM INSTRUMENT CLUSTER SYSTEM
GATEWAY-ECU (BEHIND LEFT SIDE OF DASH)
GND CLTE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HEADLIGHTS SYSTEM
HOT IN ON OR START
IG CLTB CLTS BLVL FFGO
ILE STPI HEAD
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM
JUNCTION CONNECTOR 15 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 6 (BEHIND LEFT KICK PANEL)
JUNCTION CONNECTOR 9 (BEHIND LEFT SIDE OF DASH)
LT GRN/BLK WIRE
MIRRORS SYSTEM
MPX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
STEERING PAD SWITCH (COMBINATION SWITCH)
TAIL AUTO LF KSW MIRE MIRS MIRB HRLY ALTL ACAN
TILT, TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
UNLOCK WARNING SWITCH (BEHIND LEFT SIDE OF DASH)
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Body control modules circuit (1 of 2) -> STEERING PAD SWITCH (COMBINATION SWITCH)
steering pad switch (combination switch) wiring diagram (2 of 2)
5 12 11 4 GTX+ GTX-
5 16 MPX+ MPX-
A/C CONTROL ASSEMBLY (BEHIND CENTER OF DASH)
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY ECU 1 (IN PASSENGER SIDE J/B)
BODY ECU 2 (IN DRIVER SIDE J/B)
BRN WIRE
CENTER AIR BAG
COMBINATION METER
DRIVER DOOR ECU (IN DRIVER'S DOOR)
ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT, IN ECU BOX)
FRONT PASSENGER DOOR ECU (IN RIGHT FRONT DOOR)
GATEWAY-ECU (BEHIND LEFT SIDE OF DASH)
LEFT REAR DOOR ECU (IN LEFT REAR DOOR
MOON ROOF CONTROL ECU (IN FRONT OF MOON ROOF OPENING)
MULTI-DISPLAY
ORG/ WIRE
POWER SEAT ECU (UNDER DRIVER'S SEAT)
RADIO, PLAYER
RED/BLU WIRE
RIGHT REAR DOOR ECU (IN RIGHT REAR DOOR)
SENSOR ASSEMBLY (BEHIND CENTER OF DASH, FORWARD OF CENTER CONSOLE)
STEERING PAD SWITCH (COMBINATION SWITCH)
TILT, TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
W/ MEMORY
W/ NAVIGATION
W/O MEMORY
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> High/low bus circuit -> STEERING PAD SWITCH (COMBINATION SWITCH)
