Lexus GS III (2004-2007) 3 15 2 auto head tail Wiring diagrams
This page contains all the electrical diagrams for the component. 3 15 2 auto head tail, in which he is found in the car Lexus GS III (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 3 15 2 auto head tail (1 of 2)
2 3 9 18 SIG CPUB
3 12 2 CLTS CLTE CLTB
3 15 2 AUTO HEAD TAIL
9 19 HRLY HEADLIGHTS SYSTEM
AUTOMATIC LIGHT CONTROL SENSOR (BEHIND UPPER LEFT SIDE OF DASH)
BDR
BLK WIRE
BLK/ WHT WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BODY ECU 2 (IN DRIVER SIDE J/B)
CLTB
CLTE
CLTS
COMPUTER DATA LINES SYSTEM
CTY
CTYE
D FR FUSE
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) ECU-IG FUSE
EA (AT MIDDLE OF RIGHT INNER FENDER PANEL)
EB (AT MIDDLE OF LEFT INNER FENDER PANEL)
ENGINE ROOM R/B 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
FUSE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
II (AT RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 10 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 14 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 17 (BEHIND UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 19 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR 20 (ABOVE LEFT REAR WHEELWELL)
JUNCTION CONNECTOR 6 (BEHIND LEFT KICK PANEL) IF
JUNCTION CONNECTOR 7 (BEHIND LEFT KICK PANEL)
LEFT FRONT SIDE MARKER LIGHT
LEFT LICENSE PLATE LIGHT
LEFT PARKING LIGHT
LIGHT CONTROL SWITCH COMBINATION SWITCH
ORG/ WIRE
PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT SIDE MARKER LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT PARKING LIGHT
STOP FUSE
STOP LIGHT SWITCH (ON BRAKE PEDAL BRACKET)
TAIL HEAD AUTO OFF
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> 3 15 2 AUTO HEAD TAIL
Wiring diagram 3 15 2 auto head tail (2 of 2)
1 2 3 4 5 6 7 8 IG SPDL WNG
1 2 3 4 5 6 7 8 SBF SHF SGF HDLP SBR SHR SGR
3 15 2 AUTO HEAD TAIL
8 6 11 3 12 2 BECU TRLY GND CLTS CLTE CLTB
ANTI-LOCK BRAKES SYSTEM
AUTO
AUTOMATIC LIGHT CONTROL SENSOR (BEHIND UPPER LEFT SIDE OF DASH)
BLK/BLU WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY ECU 2 (IN DRIVER SIDE J/B)
CLTB
CLTE
CLTS
COMBINATION METER
COMBINATION SWITCH
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
ECU-IG FUSE
FRONT HEIGHT CONTROL SENSOR (FORWARD OF LEFT FRONT STRUT TOWER)
FUSE
GAUGE FUSE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/RED WIRE
HEAD TAIL OFF AUTO OFF
HEADLIGHT BEAM LEVEL CONTROL ECU (AT LEFT FRONT CORNER OF ENGINE COMPT)
HEADLIGHT BEAM LEVEL CONTROL MOTOR
HEADLIGHT BEAM LEVEL CONTROL MOTOR (BEHIND RIGHT HEADLIGHT ASSEMBLY)
HEADLIGHT BEAM LEVEL CONTROL WARNING INDICATOR
HEADLIGHTS CIRCUIT
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION CONNECTOR 10 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR 6
JUNCTION CONNECTOR 6 (BEHIND LEFT KICK PANEL)
JUNCTION CONNECTOR 7 (BEHIND LEFT KICK PANEL)
LIGHT CONTROL SWITCH
PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL)
PNK/GRN WIRE
REAR HEIGHT CONTROL SENSOR (UNDER LEFT REAR OF VEHICLE)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
WHT/RED WIRE
Go to component -> Headlamps leveling circuit -> 3 15 2 AUTO HEAD TAIL
