Lexus GS II facelift (2000-2004) tail off auto head light control switch Wiring diagram
This page shows the only wiring diagram for the component.tail off auto head light control switch, which is found in the car Lexus GS II facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail off auto head light control switch (1 of 1)
15 9 HEAD HRLY
9 2 DRL
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BODY ECU 2 (IN DRIVER SIDE JUNCTION BLOCK)
COMBINATION SWITCH
DAYTIME RUNNING LIGHT RELAY (MAIN)
DIODE (BEHIND RIGHT SIDE OF DASH)
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
EB (LEFT FRONT STRUT TOWER)
ENGINE ROOM RELAY BLOCK 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
H-LP CLN FUSE
HEAD LP RELAY
HEADLIGHT CLEANER MOTOR (AT LEFT FRONT CORNER OF ENGINE COMPT, BEHIND HEADLIGHT)
HEADLIGHT CLEANER SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
J/C 10 (BEHIND LEFT SIDE OF DASH) J/C 6 (LEFT KICK PANEL)
J/C 12 (BEHIND LEFT SIDE OF DASH)
J/C 14 (BEHIND LEFT SIDE OF DASH)
MAIN FUSE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
TAIL OFF AUTO HEAD LIGHT CONTROL SWITCH
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
Go to component -> Headlamp washer circuit -> TAIL OFF AUTO HEAD LIGHT CONTROL SWITCH
