Lexus GS II facelift (2000-2004) support lumbar Wiring diagrams
This page contains all the electrical diagrams for the component. support lumbar, in which he is found in the car Lexus GS II facelift (2000-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
support lumbar wiring diagram (1 of 2)
BJ (UNDER LEFT C-PILLAR)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
D P/SEAT FUSE
DOWN
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
DRIVER'S LUMBAR SUPPORT CONTROL SWITCH
DRIVER'S POWER SEAT CONTROL SWITCH
DRIVER'S SEAT FRONT VERTICAL MOTOR (UNDER SEAT)
DRIVER'S SEAT LUMBAR MOTOR (IN SEATBACK)
DRIVER'S SEAT REAR VERTICAL MOTOR (UNDER SEAT)
DRIVER'S SEAT RECLINING MOTOR (UNDER SEAT)
DRIVER'S SEAT SLIDE MOTOR (UNDER SEAT)
FRONT
HOT AT ALL TIMES
J/C 23 (UNDER DRIVER'S SEAT)
JUNCTION CONNECTOR J/C 23 (UNDER DRIVER'S SEAT)
REAR
RECLINING
SLIDE
SUPPORT LUMBAR
VERTICAL FRONT
VERTICAL REAR
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Driver seat circuit -> SUPPORT LUMBAR
support lumbar wiring diagram (2 of 2)
BL (CENTER OF REAR SHELF)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
DOWN
FRONT
HOT AT ALL TIMES
J/C 24 (UNDER PASSEN -GER'S SEAT)
JUNCTION CONNECTOR J/C 24 (UNDER PASSENGER'S SEAT)
P-P/SEAT FUSE
PASSENGER SIDE J/B (BEHIND LEFT KICK PANEL)
PASSENGER'S LUMBAR SUPPORT CONTROL SWITCH
PASSENGER'S SEAT FRONT VERTICAL MOTOR (UNDER SEAT)
PASSENGER'S SEAT LUMBAR MOTOR (IN SEATBACK)
PASSENGER'S SEAT REAR VERTICAL MOTOR (UNDER SEAT)
PASSENGER'S SEAT RECLINING MOTOR (UNDER SEAT)
PASSENGER'S SEAT SLIDE MOTOR (UNDER SEAT)
PASSENGERS POWER SEAT CONTROL SWITCH
REAR
RECLINING
SLIDE
SUPPORT LUMBAR
VERTICAL FRONT
VERTICAL REAR
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Passenger seat circuit -> SUPPORT LUMBAR
