Lexus GS II facelift (2000-2004) left remote control mirror heater Wiring diagram
This page shows the only wiring diagram for the component.left remote control mirror heater, which is found in the car Lexus GS II facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left remote control mirror heater (1 of 1)
A/C CONTROL ASSEMBLY (BEHIND CENTER OF DASH)
ALT FUSE
BLK WIRE
BLK/ WHT WIRE
BLU WIRE
BODY ECU 1
DRIVER SIDE JUNCTION BLOCK (BEHIND LEFT KICK PANEL)
ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT, IN ECU BOX)
ENGINE ROOM RELAY BLOCK 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
HEATER FUSE
HOT AT ALL TIMES
HOT IN ON OR START
II (UPPER RIGHT SIDE OF DASH)
J/C 10 (BEHIND LEFT SIDE OF DASH)
J/C 13 (BEHIND LEFT SIDE OF DASH)
J/C 17 (BEHIND UPPER RIGHT SIDE OF DASH)
J/C 6 (LEFT KICK PANEL)
LEFT REMOTE CONTROL MIRROR HEATER
MIR HTR FUSE
MIR HTR RELAY
RED/ WHT WIRE
RED/BLU WIRE
RIGHT REMOTE CONTROL MIRROR HEATER
WHT RED/ WIRE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
Go to component -> Heated mirrors circuit -> LEFT REMOTE CONTROL MIRROR HEATER
