Lexus GS II facelift (2000-2004) htr relay Wiring diagrams
This page contains all the electrical diagrams for the component. htr relay, in which he is found in the car Lexus GS II facelift (2000-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram htr relay (1 of 2)
1 2 M+ M-
3 4 1 GAS IG GND
3.0L
4.3L
A/C AMBIENT TEMPERATURE SENSOR (NEAR TOP LEFT SIDE OF RADIATOR SUPPORT)
A/C COMP RELAY
A/C CONDENSER FAN MOTOR (IN FRONT LEFT SIDE OF RADIATOR)
A/C MAGNETIC CLUTCH, LOCK SENSOR (ON A/C COMPRESSOR)
AIR MIX CONTROL SERVO MOTOR (FRONT PASSENGER SIDE) (BEHIND RIGHT SIDE OF DASH)
BLK WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLOWER MOTOR (RIGHT SIDE OF DASH)
BLOWER MOTOR CONTROLLER (BEHIND RIGHT SIDE OF DASH)
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY ECU 1
BRN WIRE
DASH HARN, BEHIND COMBINATION METER)
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) IGN FUSE
ED (REAR SIDE OF INTAKE MANIFOLD) ED (REAR OF LEFT CYL HEAD)
ENGINE ROOM R/B 1 (ON RIGHT SIDE OF ENGINE COMPARTMENT, BEHIND STRUT TOWER)
ENGINE ROOM R/B 3 (ON LEFT SIDE OF ENGINE COMPARTMENT, FRONT OF STRUT TOWER)
EXHAUST GAS SENSOR (AT LEFT FRONT OF ENGINE COMPARTMENT)
FAN 2 RELAY
FAN 3 RELAY
GND SI B+ 2 3
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HEATER FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HTR RELAY
IG (UPPER LEFT SIDE OF DASH)
J/C 13 (BEHIND LEFT SIDE OF DASH)
J/C 14 (BEHIND LEFT SIDE OF DASH)
J/C 17 (UPPER RIGHT SIDE OF DASH)
J/C 2 (IN ECU BOX)
J/C 26 (IN ECU BOX)
LT GRN/RED WIRE
ORG/ WIRE
PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL)
PASSENGER SIDE R/B (BEHIND RIGHT KICK PANEL)
RADIATOR FAN MOTOR (LEFT FRONT OF ENGINE COMPT)
RDI FAN FUSE CDS FAN FUSE
RED WIRE
RED/BLU WIRE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Air conditioning circuits (2 of 2) -> HTR RELAY
Wiring diagram htr relay (2 of 2)
A/C COMP RELAY
A/C CONDENSER FAN MOTOR (ON FRONT LEFT SIDE OF RADIATOR)
A/C CONTROL ASSEMBLY MPX+
A/C SINGLE PRESSURE SWITCH
A/C TRIPLE PRESSURE SWITCH (AT UPPER LEFT RADIATOR SUPPORT)
ACMG
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/ORG WIRE
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
CDS FAN FUSE RDI FAN FUSE
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
EB (LEFT FRONT STRUT TOWER)
EE (UNDER ABS/ TRAC/VSC ACTUATOR)
ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT, IN ECU BOX)
ENGINE MAIN RELAY
ENGINE ROOM R/B 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
ENGINE ROOM R/B 3 (ON LEFT SIDE OF ENGINE COMPT, FRONT OF STRUT TOWER)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
FAN MAIN FUSE
GRN/YEL WIRE
HEATER FUSE
HOT AT ALL TIMES
HOT IN ON OR START
HTR RELAY
IG (UPPER LEFT SIDE OF DASH)
IGN FUSE
J/C 13 (BEHIND LEFT SIDE OF DASH)
J/C 14 (BEHIND LEFT SIDE OF DASH)
J/C 5 (IN ENGINE ROOM R/B 2)
ORG/ WIRE
PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL)
RADIATOR FAN MOTOR (AT LEFT FRONT ENGINE COMPT)
RED WIRE
RED/BLU WIRE
WATER TEMPERATURE SWITCH (AT FRONT OF ENGINE COMPT, BEHIND LEFT SIDE OF GRILLE)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Cooling fan circuit -> HTR RELAY
