Lexus GS II facelift (2000-2004) driver's power seat control switch Wiring diagram
This page shows the only wiring diagram for the component.driver's power seat control switch, which is found in the car Lexus GS II facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's power seat control switch (1 of 1)
BJ (UNDER LEFT C-PILLAR)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
D P/SEAT FUSE
DOWN
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
DRIVER'S LUMBAR SUPPORT CONTROL SWITCH
DRIVER'S POWER SEAT CONTROL SWITCH
DRIVER'S SEAT FRONT VERTICAL MOTOR (UNDER SEAT)
DRIVER'S SEAT LUMBAR MOTOR (IN SEATBACK)
DRIVER'S SEAT REAR VERTICAL MOTOR (UNDER SEAT)
DRIVER'S SEAT RECLINING MOTOR (UNDER SEAT)
DRIVER'S SEAT SLIDE MOTOR (UNDER SEAT)
FRONT
HOT AT ALL TIMES
J/C 23 (UNDER DRIVER'S SEAT)
JUNCTION CONNECTOR J/C 23 (UNDER DRIVER'S SEAT)
REAR
RECLINING
SLIDE
SUPPORT LUMBAR
VERTICAL FRONT
VERTICAL REAR
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Driver seat circuit -> DRIVER'S POWER SEAT CONTROL SWITCH
