Lexus GS II facelift (2000-2004) driver door ecu Wiring diagrams
This page contains all the electrical diagrams for the component. driver door ecu, in which he is found in the car Lexus GS II facelift (2000-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver door ecu (1 of 3)
4.3L
5 12 11 4 GTX+ GTX-
5 16 MPX+ MPX-
A/C CONTROL ASSEMBLY (BEHIND CENTER OF DASH)
BLU WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY ECU 1
BODY ECU 2
BRN WIRE
CENTER AIR BAG SENSOR ASSEMBLY (BEHIND CENTER OF DASH)
COMBINATION METER
DRIVER DOOR ECU
DRIVER SIDE J/B
ENGINE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT, IN ECU BOX)
FRONT PASSENGER DOOR ECU
GATEWAY-ECU (BEHIND LEFT SIDE OF DASH)
LEFT REAR DOOR ECU
MOON ROOF CONTROL ECU (FRONT OF MOON ROOF OPENING)
MULTI-DISPLAY
ORG/ WIRE
PASSENGER SIDE J/B
POWER SEAT ECU (UNDER DRIVER'S SEAT)
RADIO, PLAYER
RED/BLU WIRE
RIGHT REAR DOOR ECU
STEERING PAD SWITCH
TILT, TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
W/ MEMORY
W/ NAVIGATION
W/O MEMORY
W/O NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> High/low bus circuit -> DRIVER DOOR ECU
Wiring diagram driver door ecu (2 of 3)
BLK WIRE
BLK/ WHT WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG (OR BLK) WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY ECU 2
CIG FUSE
CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
D FR DOOR FUSE
D P/SEAT FUSE
D RR DOOR FUSE
DEFOGGERS, AIR CONDITIONING SYSTEMS
DRIVER DOOR ECU
ECU-IG FUSE
ENGINE ROOM R/B 1 (DIAGRAM 1 OF 2)
FOG RELAY
FR FOG FUSE
FROM
FROM ENGINE ROOM R/B 1 (DIAGRAM 1 OF 2)
FUEL OPN FUSE
FUSE
GRN WIRE
GRY WIRE
HEATER FUSE
IGN FUSE
IGNITION SWITCH
II (UPPER RIGHT SIDE OF DASH)
INSTRUMENT CLUSTER, SUPPLEMENTAL RESTRAINTS, HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
J/C 12 (BEHIND LEFT SIDE OF DASH)
J/C 15 (BEHIND LEFT SIDE OF DASH)
J/C 17 (BEHIND UPPER RIGHT SIDE OF DASH)
LEFT REAR DOOR ECU
LOCK
LT GRN WIRE
OBD FUSE
PANEL FUSE
PNK WIRE
POWER OUTLET
RADIO 2 FUSE
RED/BLU WIRE
SEATS, MEMORY SYSTEMS
SRS-B FUSE
STARTER FUSE
STARTING/ CHARGING, ENGINE CONTROLS SYSTEM
STOP FUSE
TAIL FUSE
TAIL RELAY
TRUNK, TAILGATE, FUEL DOORS SYSTEM
WASHER FUSE GAUGE FUSE
WHT WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WIPER FUSE
WIPER/ WASHER SYSTEMS
Go to component -> Power distribution circuit (2 of 2) -> DRIVER DOOR ECU
Wiring diagram driver door ecu (3 of 3)
1 5 19 GSWO KSW
1 8 IG BECU
14 15 CTYE CTY
2 3 9 12 SIG CPUB
3 15 GSW
8 1 11 BECU IG GND
BDR
BJ (UNDER LEFT C-PILLAR)
BL (CENTER OF REAR SHELF)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY ECU 1
BODY ECU 2
BSUB
BUZZER
CENTER AIRBAG SENSOR ASSEMBLY (BEHIND CENTER OF DASH)
COMBINATION METER
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DBKL GND
DRIVER DOOR ECU
DRIVER'S SIDE JUNCTION BLOCK
ECU-IG FUSE
ENGINE ROOM R/B 1
FSR+ FSR-
FUSE FUSE
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES D FR FUSE
HOT IN ACC OR RUN
HOT IN RUN OR START
II (UPPER RIGHT SIDE OF DASH)
INSTRUMENT PANEL JUNCTION BLOCK
J/C 10 (BEHIND LEFT SIDE OF DASH)
J/C 13 (BEHIND LEFT SIDE OF DASH)
J/C 15 (BEHIND LEFT SIDE OF DASH)
J/C 17 (UPPER RIGHT END OF DASH)
J/C 23 (UNDER LEFT FRONT SEAT)
J/C 24 (UNDER RIGHT FRONT SEAT)
J/C 6 (LEFT KICK PANEL)
J/C 7 (LEFT KICK PANEL)
J/C 9
LEFT BUCKLE SWITCH
LEFT FRONT DOOR COURTESY SWITCH
ORG/ WIRE
PASSENGER SIDE J/B
PASSENGER SIDE SEAT BELT WARNING LIGHT (IN CLOCK)
RADIO 2 FUSE
RBE+
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT BUCKLE SWITCH, SEAT BELT WARNING OCCUPANT DETECTION SENSOR
SEAT BELT IND
SEAT BELT WARNING OCCUPANT DETECTION SENSOR RIGHT BUCKLE SWITCH
UNLOCK WARNING SWITCH (BEHIND LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Warning system circuits -> DRIVER DOOR ECU
