Lexus GS II facelift (2000-2004) 9 19 hrly headlights system Wiring diagram
This page shows the only wiring diagram for the component.9 19 hrly headlights system, which is found in the car Lexus GS II facelift (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 9 19 hrly headlights system (1 of 1)
2 3 9 18 SIG CPUB
3 12 2 CLTS CLTE CLTB
3 15 2 AUTO HEAD TAIL
9 19 HRLY HEADLIGHTS SYSTEM
AUTOMATIC LIGHT CONTROL SENSOR (BEHIND UPPER LEFT SIDE OF DASH)
BDR
BLK WIRE
BLK/ WHT WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BODY ECU 2 (IN DRIVER SIDE J/B)
COMPUTER DATA LINES SYSTEM
CTY
CTYE
D FR DOOR FUSE
DRIVER SIDE J/B (BEHIND LEFT KICK PANEL)
EB (LEFT FRONT STRUT TOWER)
EB (RIGHT FRONT STRUT TOWER)
ECU-IG FUSE
ENGINE ROOM R/B 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
GRD
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN RUN OR START
II (UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 10 (BEHIND LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 14 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR J/C 17 (BEHIND UPPER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR J/C 19 (ABOVE LEFT REAR WHEEL- WELL)
JUNCTION CONNECTOR J/C 20 (LEFT REAR WHEELWELL)
JUNCTION CONNECTOR J/C 6 (LEFT KICK PANEL)
JUNCTION CONNECTOR J/C 7 (LEFT KICK PANEL)
LEFT FRONT DOOR COURTESY SWITCH
LEFT FRONT SIDE MARKER LIGHT
LEFT LICENSE PLATE LIGHT
LEFT PARKING LIGHT
MPX-B FUSE
ORG/ WIRE
PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT SIDE MARKER LIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT PARKING LIGHT
STOP FUSE
STOPLIGHT SWITCH (BRAKE PEDAL BRACKET)
TAIL HEAD AUTO OFF
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> 9 19 HRLY HEADLIGHTS SYSTEM
