Car Wiring Diagrams for Wiper/washer circuit for Lexus GS II (1997-2000)

BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE COMBINATION METER COMBINATION SWITCH DRIVER SIDE JUNCTION BLOCK (BEHIND LOWER LEFT END OF DASH) FRONT WIPER MOTOR (ON LEFT SIDE OF FIREWALL) GAUGE FUSE GRY/BLK WIRE HOT IN RUN OR START J/C 10 (UPPER LEFT END OF DASH) J/C 12 (UPPER LEFT SIDE OF DASH) J/C 6 (LEFT KICK PANEL) OFF RED/BLU WIRE SOLID STATE USA CANADA WASHER FUSE WASHER LEVEL WARNING LIGHT WASHER LEVEL WARNING SWITCH (AT LEFT FRONT CORNER OF ENGINE COMPT) WASHER MOTOR (RIGHT FRONT OF ENG COMPT) WASHER SWITCH WHT/BLK WIRE WIPER FUSE WIPER SWITCH YEL WIRE
