Exterior lamps circuit for Lexus GS II (1997-2000)

AUTO AUTOMATIC LIGHT CONTROL SENSOR (BEHIND UPPER LEFT SIDE OF DASH) BECU TRLY GRD CLTS CLTE CLTB BLK/ WHT WIRE BLK/RED WIRE BLU/BLK WIRE BLU/ORG WIRE BODY ECU 2 COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM GSWO AUTO HEAD TAIL CPUB CTYE BDR SIG CTY D FR DOOR FUSE DRIVER DOOR ECU (IN DRIVER'S DOOR) DRIVER SIDE JUNCTION BLOCK (BEHIND LOWER LEFT END OF DASH) ECU-IG FUSE ENGINE ROOM RELAY BLOCK 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY/RED WIRE HEADLIGHT SWITCH HOT AT ALL TIMES HOT IN RUN OR START HRLY HEADLIGHTS SYSTEM JUNCTION CONNECTOR J/C 10 (UPPER LEFT END OF DASH) JUNCTION CONNECTOR J/C 14 (BEHIND COMBINATION METER) JUNCTION CONNECTOR J/C 19 (TOP OF LEFT REAR WHEEL- WELL) JUNCTION CONNECTOR J/C 6 (LEFT KICK PANEL) JUNCTION CONNECTOR J/C 7 (LEFT KICK PANEL) LEFT FRONT DOOR COURTESY SWITCH LEFT FRONT SIDE MARKER LIGHT LEFT LICENSE PLATE LIGHT LEFT PARKING LIGHT MPX-B FUSE ORG/ WIRE PASSENGER SIDE JUNCTION BLOCK (BEHIND LOWER RIGHT END OF DASH) PPL/RED WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT SIDE MARKER LIGHT RIGHT LICENSE PLATE LIGHT RIGHT PARKING LIGHT STOP FUSE STOPLIGHT SWITCH (BRAKE PEDAL BRACKET) TAIL TAIL HEAD AUTO OFF OFF WHT WIRE WHT/ BLK WIRE WHT/BLK WIRE

1 2 3 4 5 6 7 8 9 10 11 12 BRAKE LTS HI MOUNT ALT FUSE BODY COMPUTER SYSTEM BRN WIRE COMBINATION METER DRIVER SIDE JUNCTION BLOCK (BEHIND LOWER LEFT END OF DASH) ENGINE ROOM RELAY BLOCK (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER) GAUGE FUSE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD SWITCH HIGH MOUNTED STOP LIGHT (W/ REAR SPOILER) HIGH MOUNTED STOP LIGHT (W/O REAR SPOILER) HOT AT ALL TIMES HOT IN RUN OR START JUNCTION CONNECTOR J/C 12 (BEHIND COMBINATION METER) JUNCTION CONNECTOR J/C 17 (UPPER RIGHT END OF DASH) JUNCTION CONNECTOR J/C 20 (LEFT QUARTER PANEL) LEFT LEFT FRONT STRUT TOWER) LEFT FRONT TURN SIGNAL LIGHT LEFT REAR COMBINATION LIGHT (OUTER) LEFT TURN INDIC LEFT, RIGHT REAR COMBINATION LIGHTS (INNER) LF SIGNAL TAILLT PWR HI MOUNT TAIL LTS POWER STOP SW STOP SW GRD SIDE MARKER LIGHT FAILURE SENSOR (AT LEFT SIDE OF LUGGAGE COMPARTMENT) MARKR MARKR TAIL STOP NOISE FILTER (HIGH MOUNTED STOP LIGHT) (AT LEFT FRONT CORNER OF LUGGAGE COMPT) PPL/RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT REAR COMBINATION LIGHT (OUTER) RIGHT TURN INDIC STP TL TAIL FUSE TAIL RELAY TURN TURN SIGNAL FLASHER (BEHIND LEFT SIDE OF DASH) TURN SIGNAL LIGHT SWITCH TURN STOP TAIL TURN, HAZ FUSE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE
