Lexus GS II (1997-2000) slip ind Wiring diagram
This page shows the only wiring diagram for the component.slip ind, which is found in the car Lexus GS II (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram slip ind (1 of 1)
1998-00
ABS IND.
ANTI-LOCK BRAKE SYSTEM NAVIGATION, SOUND SYSTEMS
AT-P
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BODY ECU 2 (IN DRIVER'S SIDE JUNCTION BLOCK)
BRAKE IND
BRN/YEL WIRE
BUZZER
CHARGE IND
COMBINATION METER
CRUISE IND
DOOR IND
DRIVER SIDE JUNCTION BLOCK (BEHIND LEFT KICK PANEL)
ECT POWER IND
ECT SNOW IND
ENGINE ROOM RELAY BLOCK 1 (RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM
FUEL GAUGE
FUEL IND
FUEL SENDER (IN FUEL TANK)
FUEL SENDER (SUB) (IN FUEL TANK)
GAUGE FUSE
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
HEAD IND (USA)
HEADLIGHT LEVELING IND
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM ENGINE CONTROLS SYSTEM
HIGH BEAM IND
HOT AT ALL TIMES
HOT IN RUN OR START
J/C 10 (BEHIND LEFT SIDE OF DASH)
J/C 11 (BEHIND LEFT SIDE OF DASH)
J/C 17 (BEHIND RIGHT SIDE OF DASH)
J/C 6 (LEFT KICK PANEL)
LEFT FRONT STRUT TOWER)
LEFT TURN IND
LT GRN WIRE
MALFUNCTION IND LAMP
MPX-B FUSE
ODO/TRIP
ODOMETER/ TRIPMETER
OIL LEVEL IND
OIL PRESS IND
ORG/ WIRE
PASSENGER SIDE JUNCTION BLOCK (BEHIND RIGHT KICK PANEL)
PNK WIRE
REAR LIGHT IND
RED WIRE
RED/BLU WIRE
RESET+
RHEOSTAT
RIGHT TURN IND
SEAT BELT IND
SLIP IND
SPEEDOMETER
SRS IND
SRS-B FUSE
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
TAIL IND (CANADA)
TILT AND TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
VSC IND
VSC OFF IND
WARNING SYSTEM
WASHER IND
WASHER LEVEL WARNING SWITCH (LEFT FRONT OF ENGINE COMPT)
WATER TEMP GAUGE
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit -> SLIP IND
