Lexus GS II (1997-2000) right headlight control ecu Wiring diagram
This page shows the only wiring diagram for the component.right headlight control ecu, which is found in the car Lexus GS II (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right headlight control ecu (1 of 1)
A/C LOCK SENSOR
ABS, TRAC, VSC ACTUATOR
BRN WIRE
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR 1
DATA LINK CONNECTOR 3
EFI RELAY
ENGINE CONTROL MODULE
ENGINE MAIN RELAY
ENGINE ROOM RELAY BLOCK 1 (ON RIGHT SIDE OF ENGINE COMPT, BEHIND STRUT TOWER)
HEATED OXYGEN SENSOR (BANK 1, SENSOR 2) ENGINE OIL LIFE SENSOR
HEATED OXYGEN SENSOR BANK 1 SENSOR 1 HEATED OXYGEN SENSOR BANK 2 SENSOR 1
HEATED OXYGEN SENSOR BANK 1 SENSOR 2
HEATED OXYGEN SENSOR BANK 2 SENSOR 2
IGNITER
IGNITION COIL, IGNITER 1
IGNITION COIL, IGNITER 2 IGNITION COIL, IGNITER 3
IGNITION COIL, IGNITER 4
IGNITION COIL, IGNITER 5
IGNITION COIL, IGNITER 6
IGNITION COIL, IGNITER 7
IGNITION COIL, IGNITER 8
JUNCTION CONNECTOR J/C 2 (UNDER ECU BOX)
JUNCTION CONNECTOR J/C 4 (UNDER ECU BOX)
JUNCTION CONNECTOR J/C 5 (LEFT REAR CORNER OF ENGINE COMPT)
JUNCTION CONNECTOR J/C 9 (UPPER LEFT END OF DASH)
NCA WIRE
RIGHT FRONT FOG LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT CONTROL ECU
RIGHT LOW BEAM HEADLIGHT
RIGHT PARKING LIGHT
STARTER RELAY
W/ HID
W/O HID
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 4) -> RIGHT HEADLIGHT CONTROL ECU
