Lexus GS II (1997-2000) braided vg Wiring diagram
This page shows the only wiring diagram for the component.braided vg, which is found in the car Lexus GS II (1997-2000). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram braided vg (1 of 1)
+B AUI- AUO-
1 2 3 4 5 6 7 8 9 10 11 12 13 AUI+ AUO+ PNK WIRE
1 2 TX- TX+
1 2 VR SYNC
1995 VFTC
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/ WHT WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAIDED
BRAIDED VG
BRN WIRE
DRIVER SIDE JUNCTION BLOCK (BEHIND LOWER LEFT END OF DASH)
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
ILLUM
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT PANEL JUNCTION BLOCK (BEHIND UPPER CENTER OF DASH)
JUNCTION CONNECTOR J/C 22 (UNDER RIGHT C-PILLAR)
LEFT FRONT DOOR SPEAKER
LT GRN WIRE
MEMORY SYSTEMS
MULTI-DISPLAY
NAVIGATION ECU (AT RIGHT REAR CORNER OF LUGGAGE COMPT)
ORG/ WIRE
PASSENGER SIDE JUNCTION BLOCK (BEHIND LOWER RIGHT END OF DASH)
PNK WIRE
PPL
PPL/WHT WIRE
RADIO 2 FUSE
RADIO, PLAYER
RED WIRE
SPD (VSS)
SYNC
TV FUSE
VR VG TX- BRAIDED
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit -> BRAIDED VG
