Lexus GS II (1997-2000) body ecu 2 Wiring diagrams
This page contains all the electrical diagrams for the component. body ecu 2, in which he is found in the car Lexus GS II (1997-2000). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram body ecu 2 (11 of 15)
8 6 11 BECU TRLY GRD
BDR SIG CPUB
BLK/ WHT WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY ECU 2
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
D FR DOOR FUSE
D RR DOOR FUSE
DRIVER DOOR ECU (IN DRIVER'S DOOR)
DRIVER SIDE JUNCTION BLOCK (BEHIND LOWER LEFT END OF DASH)
ECU-IG FUSE
GRD CTYE CTY A- A+ LSWE LSW KUL KL PWE MUL ML
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY WIRE
GSWO
HEADLIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ACCY OR RUN
HOT IN RUN OR START
HRLY ILE
JUNCTION CONNECTOR J/C 10 (UPPER LEFT END OF DASH)
JUNCTION CONNECTOR J/C 13 (BEHIND COMBINATION METER)
JUNCTION CONNECTOR J/C 6 (LEFT KICK PANEL)
JUNCTION CONNECTOR J/C 7 (LEFT KICK PANEL)
JUNCTION CONNECTOR J/C 8 (LEFT FRONT DOOR SILL)
LEFT DOOR LOCK CONTROL SWITCH (POWER WINDOW MASTER SWITCH)
LEFT FRONT DOOR COURTESY SWITCH
LOCK DETECT
LT GRN/BLK WIRE
LT GRN/RED WIRE
ORG/ WIRE
PNK/BLK WIRE
PNK/GRN WIRE
RADIO 2 FUSE
RED/GRN WIRE
RED/YEL WIRE
UNLK LOCK
WHT WIRE
WHT/BLK WIRE
Go to component -> Keyless entry & anti-theft circuit (1 of 3) -> BODY ECU 2
Wiring diagram body ecu 2 (12 of 15)
1 16 BDR MSWE
2 12 3 1 7 8 10 13 16 SIG PVC CPUB VSSR PM+R PMVR HSSR
6 7 8 MIRE MIRS MIRB
9 15 14 4 2 12 3 1 7 8 10 13 16 PNK WIRE
BDR
BLK/ORG WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BODY ECU 1
BODY ECU 2
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
D FR DOOR FUSE
DMHR
DOWN SELECT SWITCH LH
DRIVER DOOR ECU (IN DRIVER'S DOOR)
DRIVER SIDE JUNCTION BLOCK (BEHIND LOWER LEFT END OF DASH)
DRIVING POSITION AND MEMORY CONTROL SWITCH
DVC
ECU-IG FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GSWO
HOT AT ALL TIMES
HOT IN ACCY OR RUN
HOT IN ON OR START
HSR
J/C 10 (UPPER LEFT END OF DASH)
J/C 15 (LEFT SIDE OF DASH)
J/C 17 (UPPER RIGHT END OF DASH)
J/C 6 (LEFT KICK PANEL)
J/C 7 (LEFT KICK PANEL)
J/C 8 (LEFT KICK PANEL)
LEFT
LEFT REMOTE CONTROL MIRROR
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MEM 2 PNK MEM 1 WIRE
MM SIG GND CPUB VSSR DM+R DMVR HSSR
MPX-B FUSE
OPERATION SWITCH
ORG/ WIRE
P FR DOOR FUSE
PASSENGER DOOR ECU (IN RIGHT FRONT DOOR)
PASSENGER JUNCTION BLOCK (BEHIND LOWER RIGHT END OF DASH)
PMHR
PNK/BLK WIRE
PVC
RADIO 2 FUSE
RED WIRE
RED/BLU WIRE
REMOTE CONTROL MIRROR SWITCH
RIGHT
RIGHT REMOTE CONTROL MIRROR
SET-
VIO WIRE
VSR
WHT WIRE
WHT/BLK WIRE
YEL/RED WIRE
Go to component -> Memory system circuits (1 of 2) -> BODY ECU 2
Wiring diagram body ecu 2 (13 of 15)
1 4 (2001) (1998 - 2000)
2 12 3 7 8 16 SIG GND CPUB PM+R PMVR PMHR
6 6 2 5 (2001) (1998 - 2000)
6 7 8 MIRE MIRS MIRB
BDR
BLK/RED WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BODY ECU 1
BODY ECU 2
BRN/BLK WIRE
BSUB
COMPUTER DATA LINES SYSTEM
D FR DOOR FUSE
DOWN SELECT SWITCH LH
DRIVER DOOR ECU (IN DRIVER'S DOOR)
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
ECU-IG FUSE
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GSW
GSWO
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN RUN OR ACCY
J/C 10 (UPPER LEFT END OF DASH)
J/C 15 (LEFT SIDE OF DASH)
J/C 17 (UPPER RIGHT END OF DASH)
J/C 6 (LEFT KICK PANEL)
J/C 7 (LEFT KICK PANEL)
LEFT
LEFT REMOTE CONTROL MIRROR
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MPX-B FUSE
OPERATION SWITCH
ORG/ WIRE
P FR DOOR FUSE
PASSENGER DOOR ECU (IN RIGHT FRONT DOOR)
PASSENGER SIDE J/B (BEHIND LOWER RIGHT END OF DASH)
RADIO 2 FUSE
REMOTE CONTROL MIRROR SWITCH
RIGHT
RIGHT REMOTE CONTROL MIRROR
SIG GND CPUB DM+R DMVR DMHR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power mirrors circuit -> BODY ECU 2
Wiring diagram body ecu 2 (14 of 15)
AUTO
BDR SIG CPUB
BLK/ WHT WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY ECU 2
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
CTYE CTY LSWE KUL KL
D FR DOOR FUSE
D RR DOOR FUSE
DOWN
DRIVER DOOR ECU (IN DRIVER'S DOOR)
DRIVER SIDE JUNCTION BLOCK (BEHIND LOWER LEFT END OF DASH)
ECU-IG FUSE
GRD
GRD PLS LMT SGRD UP DN PWE WLSW AUTO MDN
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
GSWO
HOT AT ALL TIMES
HOT IN ACCY OR RUN
HOT IN RUN OR START
JUNCTION CONNECTOR J/C 10 (UPPER LEFT END OF DASH)
JUNCTION CONNECTOR J/C 13 (BEHIND COMBINATION METER)
JUNCTION CONNECTOR J/C 6 (LEFT KICK PANEL)
JUNCTION CONNECTOR J/C 7 (LEFT KICK PANEL)
JUNCTION CONNECTOR J/C 8 (LEFT FRONT DOOR SILL)
M/UP
ORG/ WIRE
PNK/BLK WIRE
PNK/GRN WIRE
POWER WINDOW MASTER SWITCH
PPL
PPL/RED WIRE
PPL/WHT WIRE
RADIO 2 FUSE
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
UNLK LOCK
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WINDOW LOCK SWITCH
YEL WIRE
YEL/GRN WIRE
Go to component -> Power window circuit (1 of 3) -> BODY ECU 2
Wiring diagram body ecu 2 (15 of 15)
1 11 IG GND
1 5 19 GSWO KSW
1 8 IG BECU
14 15 CTYE CTY
2 3 9 12 SIG CPUB
3 15 18 19 GSW
4 8 BSUB BECU
BDR
BLK/BLU WIRE
BLK/ORG WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY ECU 1
BODY ECU 2
C P U
COMBINATION METER
COMPUTER DATA LINES
D FR DOOR FUSE
DBKL GND
DRIVER DOOR ECU
DRIVER'S SIDE JUNCTION BLOCK
ECU-IG FUSE
ENGINE ROOM RELAY BLOCK 1
GAUGE FUSE
GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES PASSENGER SIDE JUNCTION BLOCK P FR DOOR FUSE
HOT IN ACC OR RUN
HOT IN RUN OR START
INSTRUMENT PANEL JUNCTION BLOCK
J/C 10 (BEHIND LEFT SIDE OF DASH)
J/C 13 (BEHIND COMBINATION METER)
J/C 15 (UPPER LEFT SIDE OF DASH)
J/C 17 (UPPER RIGHT END OF DASH)
J/C 23 (UNDER DRIVER'S SEAT)
J/C 6 (LEFT KICK PANEL)
J/C 7 (LEFT KICK PANEL)
J/C 9
LEFT BUCKLE SWITCH
LEFT FRONT DOOR COURTESY SWITCH
MPX-B FUSE
ORG/ WIRE
PASSENGER SIDE SEAT BELT WARNING LIGHT (IN CLOCK)
PBKL
RADIO 2 FUSE
RED/BLU WIRE
RED/GRN WIRE
RIGHT BUCKLE SWITCH
SEAT BELT IND
SEAT BELT WARNING OCCUPANT DETECTION SENSOR
UNLOCK WARNING SWITCH (BEHIND LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Warning system circuits -> BODY ECU 2
Page 2 of 2
