Anti-theft circuit for Lexus GS I (1993-1997)

2 11 3 4 6 8 9 10 7 12 B+ LSWR IG UL BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE COMBINATION METER (LEFT SIDE OF I/P) DSWD DSWP KSW LSWP ECU-IG FUSE POWER FUSE ENGINE HOOD COURTESY SWITCH (CENTER FRONT OF ENG COMPT) EXTERIOR LIGHTS SYSTEM (TAIL LIGHT RELAY) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHTS SYSTEM (HEADLIGHT RELAY) HORNS SYSTEM (HORN RELAY) HOT AT ALL TIMES HOT IN RUN IGNITION/ UNLOCK WARNING SWITCH (BEHIND STEERING WHEEL) INTERIOR LIGHTS SYSTEM (LUGGAGE COMPT LIGHT) J/B 1 (LEFT SIDE OF I/P) J/B 3 (CENTER OF I/P) J/B 6 (LEFT SIDE OF I/P) LEFT FRONT DOOR LOCK AND UNLOCK SWITCH (REARWARD OF LEFT DOOR) LSWD LSWP CTY LSWR CTY DSWL LUG HEAD SH IND TSW DSWH LSWD LUGGAGE COMPARTMENT LIGHT SWITCH (CENTER REAR OF TRUNK) OPEN DOOR WARNING LAMP PNK/BLU WIRE POWER MAIN RELAY POWER WINDOW/ DOOR LOCK CONTROL SWITCH (CENTER OF LEFT DOOR) POWER WINDOWS AND OR POWER TOPS PRLY IG RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR LOCK AND UNLOCK SWITCH (REARWARD OF RIGHT DOOR) RIGHT FRONT DOOR LOCK CONTROL SWITCH (CENTER OF RIGHT DOOR) STARTING/CHARGING SYSTEM (STARTER RELAY) TAIL HORN SRLY THEFT DETERRENT ECU (LEFT SIDE OF I/P) THEFT DETERRENT INDICATOR LIGHT (LEFT SIDE OF I/P) TO ACT- ACT+ WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WIRELESS DOOR LOCK ECU (RIGHT REAR OF TRUNK) WIRELESS DOOR LOCK MAIN SWITCH YEL/GRN WIRE

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE DOME FUSE GRN WIRE GRN/YEL WIRE GRY WIRE HAZ-HORN FUSE HOT AT ALL TIMES HOT RUN OR ACCY J/B 1 (LEFT SIDE OF I/P) J/B 1 (LEFT SIDE OF I/P) CIG FUSE J/B 2 (LEFT ENG COMPT) J/B 3 (CENTER OF I/P) J/C 5 (LEFT SIDE OF I/P) J/C 7 (CENTER OF I/P) LEFT FRONT DOOR COURTESY SWITCH (NEAR LEFT REAR DOOR LATCH) LEFT REAR DOOR COURTESY SWITCH (NEAR LEFT REAR DOOR LATCH) LUGGAGE COMPARMENT DOOR OPENER MOTOR (CENTER REAR OF TRUNK) LUGGAGE COMPARTMENT DOOR OPENER SWITCH (LEFT SIDE OF I/P) LUGGAGE COMPARTMENT KEY UNLOCK SWITCH PNK/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COURTESY SWITCH (NEAR LEFT REAR DOOR LATCH) RIGHT FRONT DOOR LOCK MOTOR AND DOOR UNLOCK DETECTION SWITCH RIGHT REAR DOOR COURTESY SWITCH (NEAR RIGHT REAR DOOR LATCH) THEFT DETERRENT HORN (LEFT REAR OF ENG COMPT) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE
