Lexus GS I (1993-1997) fully/semi concealed changeover switch Wiring diagram
This page shows the only wiring diagram for the component.fully/semi concealed changeover switch, which is found in the car Lexus GS I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fully/semi concealed changeover switch (1 of 1)
+1 S/M M/B S/S +B
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG (OR BLU/WHT) WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT (OR BLU/RED) WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMBINATION SWITCH
FULL
FULLY/SEMI CONCEALED CHANGEOVER SWITCH
GRN WIRE
HOT IN RUN
INT TIME CONTROL SWITCH
J/B #1 (AT LEFT KICK PANEL)
J/B 3 (CENTER OF I/P)
J/C 11
J/C 2 (LEFT SIDE OF I/P)
J/C 5 (LEFT SIDE OF I/P)
J/C 7 (CENTER OF I/P)
LO HI
LO HI OFF INT
LT GRN WIRE
LT GRN/RED WIRE
M/F CO 17 18
OFF INT
ON WASHER SWITCH
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
SEMI
VIO (OR YEL) WIRE
VIO/GRN WIRE
WASHER MOTOR
WHT WIRE
WHT/BLK WIRE
WIPER ANGLE CONTROL MOTOR (LEFT SIDE OF SAFETY WALL)
WIPER FUSE
WIPER MOTOR
WIPER RELAY (BEHIND LEFT SIDE OF I/P)
WIPER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> FULLY/SEMI CONCEALED CHANGEOVER SWITCH
