Lexus GS I (1993-1997) combination switch light control switch Wiring diagram
This page shows the only wiring diagram for the component.combination switch light control switch, which is found in the car Lexus GS I (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch light control switch (1 of 1)
AUTO
AUTO OFF OFF HEAD TAIL
AUTOMATIC LIGHT SENSOR (BEHIND LEFT SIDE OF I/P) IG
BLK WIRE
BLU WIRE
COMBINATION SWITCH LIGHT CONTROL SWITCH
CTY
DIMMER SWITCH
FOG FUSE
FOG LIGHT RELAY
FOG LIGHT SWITCH LO
GRN WIRE
HEAD TAIL
HIGH FLASH FLASH LO
HIGH LO
HOT AT ALL TIMES
HOT IN RUN J/B 1 ECU-IG (LEFT KICK PANEL) FUSE
INTEGRATION RELAY
J/B 1 (LEFT KICK PANEL)
J/B 3 (BEHIND CENTER OF I/P)
J/B 3 (CENTER OF I/P)
J/C 11 (BEHIND CLUSTER)
J/C 12 (LEFT SIDE OF TRUNK)
J/C 2 (LEFT SIDE OF I/P)
LEFT FOG LIGHT
LEFT FRONT DOOR COURTESY SWITCH
OFF
ORG/ WIRE
R/B 2 (LEFT SIDE OF ENGINE COMPARTMENT) DOME FUSE
R/B 6 (LEFT KICK PANEL)
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT FOG LIGHT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlight circuit, with drl (2 of 2) -> COMBINATION SWITCH LIGHT CONTROL SWITCH
