Car Wiring Diagrams for Immobilizer circuit for Lexus GS F I (2015-2020)

BLU WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM ECU-B FUSE ENGINE ROOM R/B 1 ASSEMBLY GRY WIRE HOT AT ALL TIMES ID CODE BOX (CENTER OF DASH) IMI PNK IMO WIRE LT GRN WIRE PNK WIRE RED WIRE RIGHT END OF DASH) STEERING COLUMN) STEERING LOCK ACTUATOR ASSEMBLY WHT WIRE WHT/BLK WIRE
