Lexus ES XV70 facelift (2021-2024) steering lock actuator assembly/ upper bracket assembly Wiring diagram
This page shows the only wiring diagram for the component.steering lock actuator assembly/ upper bracket assembly, which is found in the car Lexus ES XV70 facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering lock actuator assembly/ upper bracket assembly (1 of 1)
BLK WIRE
CERTIFICATION ECU (SMART KEY ECU ASSEMBLY)
COMPUTER DATA LINES SYSTEM
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
GRN WIRE
HOT AT ALL TIMES
ID CODE BOX (IMMOBILIZER CODE ECU)
IGE
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
LT GRN WIRE
ORG/ WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SL/R
SLP
STEERING COLUMN)
STEERING LOCK ACTUATOR ASSEMBLY/ UPPER BRACKET ASSEMBLY
STRG LOCK FUSE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Steering column circuit -> STEERING LOCK ACTUATOR ASSEMBLY/ UPPER BRACKET ASSEMBLY
