Car Wiring Diagrams for Immobilizer circuit for Lexus ES XV70 (2018-2021)

BLK WIRE BLU WIRE CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) COMPUTER DATA LINES SYSTEM ECM (EXCEPT HYBRID) ECU-B 1 FUSE GRN WIRE HOT AT ALL TIMES HYBRID EXCEPT HYBRID HYBRID VEHICLE CONTROL ECU ID CODE BOX (IMMOBILIZER CODE ECU) IMO CANH INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY LT GRN WIRE RIGHT END OF DASH) STEERING COLUMN) STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
