Lexus ES XV70 (2018-2021) ppl ga Wiring diagram
This page shows the only wiring diagram for the component.ppl ga, which is found in the car Lexus ES XV70 (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl ga (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
DOOR CONTROL SWITCH ASSEMBLY
DRIVER'S DOOR
GE (RIGHT END OF DASH)
GRN WIRE
GRY WIRE
ILL
LT GRN WIRE
LUGGAGE CLOSER MOTOR ASSEMBLY
LUGGAGE CLOSER SWITCH (DOOR CONTROL SWITCH)
MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
MULTI- DISPLAY ASSEMBLY
ORG/ WIRE
OUTER MIRROR SWITCH ASSEMBLY
PPL
PPL GA
PPL/BLU WIRE
PPL/RED WIRE
RED WIRE
RIGHT END OF DASH)
TAIL
VIO WIRE
VSC OFF SWITCH
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument illumination circuit (2 of 4) -> PPL GA
