Lexus ES XV70 (2018-2021) intermittent time adjustment switch/ auto wiper sensitivity adjustment switch Wiring diagram
This page shows the only wiring diagram for the component.intermittent time adjustment switch/ auto wiper sensitivity adjustment switch, which is found in the car Lexus ES XV70 (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intermittent time adjustment switch/ auto wiper sensitivity adjustment switch (1 of 1)
AUTO
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
GRN WIRE
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY
INTERMITTENT TIME ADJUSTMENT SWITCH/ AUTO WIPER SENSITIVITY ADJUSTMENT SWITCH
LT BLU WIRE
MIST
OFF
PPL
PPL/ORG WIRE
RED WIRE
RELAY ENERGIZED
STEERING COLUMN)
STEERING SENSOR
W-OFF
WASHER FLUID RESERVOIR)
WASHER FUSE
WASHER RELAY
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER MOTOR ASSEMBLY
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER FUSE
WIPER RELAY
WIPER SWITCH
Go to component -> Wiper/washer circuit (1 of 2) -> INTERMITTENT TIME ADJUSTMENT SWITCH/ AUTO WIPER SENSITIVITY ADJUSTMENT SWITCH
