Car Wiring Diagrams for Heated seats circuit for Lexus ES XV60 facelift (2015-2018)

AIR CONDITIONING SYSTEM BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ECU-ACC FUSE ECU-B 2 FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC 1 RELAY ENERGIZED INSTRUMENT PANEL J/B ASSEMBLY LEFT REAR SEAT HEATER CONTROL SUB-ASSEMBLY LT BLU WIRE LT GRN WIRE PNK WIRE POWER WINDOWS SYSTEM REAR CONTROL SWITCH REAR SEAT HEATER SWITCH, TEMPERATURE SWITCH, REAR SUNSHADE SWITCH RED WIRE RELAY ENERGIZED RIGHT REAR SEAT HEATER CONTROL SUB-ASSEMBLY S/HTR RR FUSE VIO WIRE WHT WIRE WHT/BLK WIRE
