Passive restraints circuit for Lexus ES XV60 facelift (2015-2018)
Passive restraints circuit
BLK WIRE
BLU WIRE
BUCKLE SWITCH
GRY WIRE
INSTRUMENT PANEL J/B ASSEMBLY
LEFT "C" PILLAR)
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT FRONT SEAT OUTER BELT ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY (LEFT FRONT POWER SEAT SWITCH)
RELAY ENERGIZED
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT FRONT SEAT OUTER BELT ASSEMBLY
VIO WIRE
W/ MEMORY
W/O MEMORY
WHT/BLK WIRE
