Car Wiring Diagrams for Immobilizer circuit for Lexus ES XV60 facelift (2015-2018)

BLK WIRE CERTIFICATION ECU COMPUTER DATA LINES SYSTEM ENGINE ROOM R/B ASSEMBLY GRN WIRE HOT AT ALL TIMES ID CODE BOX LT BLU WIRE LT GRN WIRE RED WIRE SMART FUSE STEERING COLUMN) STEERING LOCK ACTUATOR ASSEMBLY WHT WIRE WHT/BLK WIRE YEL WIRE
