Lexus ES XV60 facelift (2015-2018) steering pad switch Wiring diagram
This page shows the only wiring diagram for the component.steering pad switch, which is found in the car Lexus ES XV60 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering pad switch (1 of 1)
+BM
ACCELERATOR PEDAL SENSOR ASSEMBLY
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY
BRN WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MAIN SWITCH
DISTANCE CONTROL
EFI 1 FUSE
EFI 2 FUSE
EFI MAIN RELAY
EFI- MAIN 1 FUSE
ENGINE ROOM R/B ASSEMBLY
ETCS FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTEGRATION RELAY
LEFT FRONT SPEED SENSOR
LEFT REAR SPEED SENSOR
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RIGHT FRONT SPEED SENSOR
RIGHT REAR SPEED SENSOR
RIGHT STEERING PAD SWITCH
SHIFT POSITION INDICATOR
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING PAD SWITCH
STPS
THROTTLE BODY W/ MOTOR ASSEMBLY (RIGHT REAR OF INTAKE MANIFOLD)
TRANSMISSION CONTROL ECU ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit, w/ dynamic radar controls (1 of 2) -> STEERING PAD SWITCH
