Lexus ES XV60 facelift (2015-2018) computer data lines system Wiring diagrams

A/C AMPLIFIER ASSEMBLY A/C-B FUSE BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DEICER FUSE DEICER RELAY ENGINE ROOM R/B 2 ASSEMBLY ENGINE ROOM R/B ASSEMBLY FDEF FRONT WIPER DEICER (WINDSHIELD GLASS) GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B ASSEMBLY RADIO RECEIVER ASSEMBLY RED WIRE RELAY ENERGIZED VIO WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BLK WIRE

BLK WIRE BLU WIRE BRN WIRE CAN I/F CERTIFICATION ECU (RIGHT SIDE OF DASH) CLOSE CLS COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DISPLAY DRIVER DOWN DWN ECU-ACC FUSE ECU-B 1 FUSE ENGINE ROOM R/B ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC 1 RELAY ENERGIZED ILLB INSTRUMENT PANEL J/B ASSEMBLY LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY LILL LT GRN WIRE MAIN BODY ECU OPN PNK WIRE RED WIRE RELAY ENERGIZED ROOF CONSOLE BOX ASSEMBLY S/ROOF FUSE SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY) SLIDING ROOF SWITCH IND VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE CANN CANP CERTIFICATION ECU (RIGHT SIDE OF DASH) CLS CLUTCH COMPUTER DATA LINES SYSTEM CPS+ CPSE CSEL CSG CSV PNK PAWL WIRE CSWE DATA DOOR CONTROL SWITCH ECU-ACC FUSE ECU-B 1 FUSE ECUB ENGINE ROOM R/B ASSEMBLY FSW+ GRN WIRE GRY WIRE HAF HALF HOT AT ALL TIMES HOT W/ ACC 1 RELAY ENERGIZED ILL INSTRUMENT PANEL J/B ASSEMBLY LCM+ LDDN LEFT "C" PILLAR) LT GRN WIRE LUGGAGE CLOSER MOTOR ASSEMBLY LUGGAGE DOOR CLOSER ASSEMBLY (CENTER REAR OF LUGGAGE COMPT LID) LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY LUGGAGE DOOR OPENING SWITCH ASSEMBLY LUGGAGE ELECTRICAL KEY SWITCH MAIN BODY ECU (IN INSTRUMENT PANEL JUNCTION BOX) PAWL PNK WIRE POWER TRUNK LID CLOSE SWITCH PTL FUSE RCO RDAM RED WIRE RELAY ENERGIZED SWG TMSW TSW VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE

A/C AMPLIFIER ASSEMBLY ALT FUSE ALT IGN BDR BLK WIRE BLK/RED WIRE BLU WIRE BRN/WHT WIRE CANN CANP COMPUTER DATA LINES SYSTEM DEF DEFS ENGINE ROOM J/B ASSEMBLY F/L DOOR FUSE F/R DOOR FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HTR INSTRUMENT PANEL J/B ASSEMBLY INTEGRATION RELAY (ENGINE ROOM JUNCTION BLOCK ASSEMBLY) LEFT "C" PILLAR) LEFT OUTER MIRROR CONTROL ECU ASSEMBLY LEFT OUTER REAR VIEW MIRROR ASSEMBLY MIRROR HEATER NOISE FILTER (REAR WINDOW DEFOGGER) RADIO RECEIVER ASSEMBLY RDFG REAR WINDOW DEFOGGER (BACK WINDOW GLASS) RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY RIGHT OUTER REAR VIEW MIRROR ASSEMBLY VIO WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BLK WIRE

A/C AMPLIFIER ASSEMBLY ALT FUSE ALT IGN BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DEF DEFS ENGINE ROOM J/B ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ INSTRUMENT PANEL J/B ASSEMBLY INTEGRATION RELAY (ENGINE ROOM JUNCTION BLOCK ASSEMBLY) LEFT "C" PILLAR) LEFT OUTER REAR VIEW MIRROR ASSEMBLY MHTR MIRROR HEATER NOISE FILTER (REAR WINDOW DEFOGGER) RADIO RECEIVER ASSEMBLY RDFG REAR WINDOW DEFOGGER (BACK WINDOW GLASS) RED WIRE RIGHT OUTER REAR VIEW MIRROR ASSEMBLY VIO WIRE W/ NAVIGATION W/O NAVIGATION WHT WIRE WHT/BLK WIRE YEL WIRE

BKUP LP FUSE BLK WIRE BLU WIRE BRN WIRE CAN (+) COMPUTER DATA LINES SYSTEM DIO DIODE (BACKUP LIGHT) ECU-ACC FUSE EFI 1 FUSE EFI 2 FUSE EFI MAIN RELAY EFI- MAIN 1 FUSE ENGINE ROOM J/B ASSEMBLY ENGINE ROOM R/B ASSEMBLY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC 1 RELAY ENERGIZED INSTRUMENT PANEL J/B ASSEMBLY OIL PRESSURE SWITCH TEMPERATURE SENSOR ORG/ WIRE PARK/NEUTRAL POSITION SWITCH ASSEMBLY PNK DIO+ WIRE PNK WIRE RED WIRE RELAY ENERGIZED STARTING/ CHARGING SYSTEM TRANSMISSION CONTROL ECU ASSEMBLY WHT WIRE WHT/BLK WIRE YEL WIRE

BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY BRN WIRE CAN (+) CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE HOT AT ALL TIMES IG+ ES INSTRUMENT PANEL J/B ASSEMBLY INTEGRATION CONTROL, LED LT GRN WIRE NORMAL MODE ORG/ WIRE PANEL ASSEMBLY PNK WIRE PWMS RED WIRE RELAY ENERGIZED SFTD SFTU SHIFT POSITION INDICATOR SPCN SPEAKER SPORTS MODE STOP FUSE STOP LIGHT SWITCH ASSEMBLY TELLTALES WHT WIRE WHT/BLK WIRE YEL WIRE

ALT FUSE BLK WIRE BLU WIRE CERTIFICATION ECU (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM ECU-ACC FUSE ECU-B 1 FUSE ENGINE ROOM J/B ASSEMBLY ENGINE ROOM R/B ASSEMBLY FUEL FILLER DOOR, FUEL LID OPENER SWITCH FUEL LID W/ MOTOR LOCK ASSEMBLY FUEL OPN FUSE FUEL OPN RELAY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC 1 RELAY ENERGIZED INSTRUMENT PANEL J/B ASSEMBLY LEFT "C" PILLAR) LGCY LT GRN WIRE LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY LUGGAGE DOOR OPENING SWITCH ASSEMBLY LUGGAGE ELECTRICAL KEY SWITCH MAIN BODY ECU (IN INSTRUMENT PANEL JUNCTION BOX) RED WIRE RELAY ENERGIZED TMSW TRK OPN RELAY TSW VIO WIRE WHT WIRE WHT/BLK WIRE

+SM ADJUSTMENT SWITCH AUTO AUTO WIPER SENSITIVITY BLK WIRE BLU WIRE BRN WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE HIGH LOW IG+ PNK WIRE INSTRUMENT PANEL J/B ASSEMBLY LEVEL WARNING SWITCH ASSEMBLY LT GRN WIRE MIST MPX OFF OFF MIST ORG/ WIRE PNK WIRE RAIN SENSOR RED WIRE RELAY ENERGIZED ROOF CONSOLE BOX ASSEMBLY S-AUTO SIG VIO WIRE WASHER FLUID RESERVOIR) WASHER FUSE WASHER SWITCH WHT WIRE WHT/BLK WIRE WIG WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY WINDSHIELD WIPER MOTOR ASSEMBLY (LEFT REAR OF ENGINE COMPT) WINDSHIELD WIPER RELAY ASSEMBLY WINDSHIELD WIPER SWITCH ASSEMBLY WIPER FUSE WIPER SWITCH YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM FAST GRN WIRE GRY WIRE INSTRUMENT PANEL J/B ASSEMBLY INTERMITTENT TIMING SWITCH LEVEL WARNING SWITCH ASSEMBLY LO HI LT GRN WIRE MIST OFF PNK WIRE RED WIRE SLOW WASHER FLUID RESERVOIR) WASHER FUSE WASHER SWITCH WHT WIRE WHT/BLK WIRE WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY WINDSHIELD WIPER MOTOR ASSEMBLY WINDSHIELD WIPER SWITCH ASSEMBLY WIPER FUSE WIPER SWITCH
