Lexus ES XV60 facelift (2015-2018) adjustment switch Wiring diagram
This page shows the only wiring diagram for the component.adjustment switch, which is found in the car Lexus ES XV60 facelift (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adjustment switch (1 of 1)
+SM
ADJUSTMENT SWITCH
AUTO
AUTO WIPER SENSITIVITY
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
HIGH LOW
IG+ PNK WIRE
INSTRUMENT PANEL J/B ASSEMBLY
LEVEL WARNING SWITCH ASSEMBLY
LT GRN WIRE
MIST
MPX
OFF
OFF MIST
ORG/ WIRE
PNK WIRE
RAIN SENSOR
RED WIRE
RELAY ENERGIZED
ROOF CONSOLE BOX ASSEMBLY
S-AUTO
SIG
VIO WIRE
WASHER FLUID RESERVOIR)
WASHER FUSE
WASHER SWITCH
WHT WIRE
WHT/BLK WIRE
WIG
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WINDSHIELD WIPER MOTOR ASSEMBLY (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER RELAY ASSEMBLY
WINDSHIELD WIPER SWITCH ASSEMBLY
WIPER FUSE
WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit, w/ auto wiper system -> ADJUSTMENT SWITCH
