Heated steering wheel circuit for Lexus ES XV60 (2012-2015)
Heated steering wheel circuit
BLU WIRE
COMBINATION SWITCH ASSEMBLY
FUSE
GRN WIRE
GRY WIRE
HEATER CONTROL ASSEMBLY
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (LEFT END OF DASH)
LT BLU WIRE
ORG/ WIRE
PNK IN WIRE
PNK WIRE
RELAY ENERGIZED
SPIRAL CABLE (STEERING COLUMN)
STEERING HEATER
STEERING WHEEL HEATER CONTROL ASSEMBLY
STRG HTR FUSE
STRG HTR RELAY ENGINE ROOM R/B 2 (RIGHT REAR OF ENGINE COMPT)
VIO WIRE
WHT/BLK WIRE
