Backup lamps circuit for Lexus ES XV60 (2012-2015)
Backup lamps circuit
BACKUP
BKUP LP FUSE
BLU WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
INSTRUMENT PANEL J/B (LEFT END OF DASH)
LEFT REAR LIGHT ASSEMBLY
LT BLU WIRE
PARK/NEUTRAL POSITION SWITCH (TRANSMISSION ASSEMBLY)
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT REAR LIGHT ASSEMBLY
TRANSMISSION CONTROL ECU (LEFT SIDE OF TRANSMISSION)
WHT/BLK WIRE
