Immobilizer circuit for Lexus ES XV60 (2012-2015)

Immobilizer circuit

Get access

BLK WIRE CERTIFICATION ECU (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT) EFII EFIO ENGINE GRN WIRE HOT AT ALL TIMES ID CODE BOX (LEFT SIDE OF DASH) IMI IMO LIN LT BLU WIRE LT GRN WIRE RED WIRE SMART ROOM R/B FUSE (LEFT SIDE OF ENGINE COMPT) STEERING LOCK ACTUATOR ASSEMBLY (STEERING COLUMN) WHT WIRE WHT/BLK WIRE YEL WIRE
