Lexus ES XV60 (2012-2015) (w/o memory) outer mirror switch assembly wiring diagram
This page shows the only wiring diagram for the component.(w/o memory) outer mirror switch assembly, which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
(w/o memory) outer mirror switch assembly wiring diagram (1 of 1)
A/C AMPLIFIER ASSEMBLY
AIR BAG SENSOR ASSEMBLY
AUTO HIGH BEAM SWITCH
AUTOMATIC LIGHT CONTROL SENSOR
BLK WIRE
CIGARETTE LIGHTER ASSEMBLY
CLOCK ASSEMBLY
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR
DOOR CONTROL SWITCH ASSEMBLY
DRIVER ALL DOOR DOOR LOCK UNLOCK RELAY RELAY
FROM GROUND
HEADLIGHT DIMMER SWITCH ASSEMBLY
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT RIGHT VISOR VISOR ASSEMBLY ASSEMBLY
MAIN BODY RELAY ECU
MULTIPLEX TILT, TELESCOPIC ECU
NCA WIRE
OPTION CONNECTOR (GLASS BREAKAGE SENSOR)
OPTION CONNECTOR (REMOTE ENGINE STARTER)
P, RR, RL DOOR UNLOCK RELAY
POWER OUTLET SOCKET ASSEMBLY
POWER OUTLET SOCKET ASSEMBLY 1
RELAY
RELAY RELAY
RIGHT FRONT DOOR LOCK ASSEMBLY
RIGHT FRONT ELECTRICAL KEY ANTENNA
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT REFRESHING SEAT SWITCH
ROOF CONSOLE BOX ASSEMBLY
SHIFT LOCK CONTROL ECU (LOWER LEFT SHIFT REFRESHING LEVER SEAT ASSEMBLY) SWITCH
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN)
STEERING GLOVE BOX LOCK LIGHT ACTUATOR ASSEMBLY ASSEMBLY
STEERING SENSOR
STEERING WHEEL HEATER CONTROL ASSEMBLY STEERING HEATER
TRK ACC 1 ACC 2 OPEN RELAY RELAY RELAY
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Ground distribution circuit (3 of 6) -> (W/O MEMORY) OUTER MIRROR SWITCH ASSEMBLY
