Lexus ES XV60 (2012-2015) pnk head tail Wiring diagram
This page shows the only wiring diagram for the component.pnk head tail, which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk head tail (1 of 1)
20 21 22 23 24 25 26 27 28 FSPT
A/C AMPLIFIER (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
CANL CANH REV RDA
CERTIFICATION ECU (RIGHT SIDE OF DASH)
CLEARANCE WARNING ECU (W/ PARKING ASSISTANT) (RIGHT SIDE OF DASH)
COMBINATION METER ASSEMBLY
DOOR LOCKS, ANTI-THEFT SYSTEMS
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HEADLIGHTS SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS, INTERIOR LIGHTS SYSTEMS
HEADLIGHTS SYSTEM INTERIOR LIGHTS SYSTEM DOOR LOCKS SYSTEM HEADLIGHTS SYSTEM
LSFR LGCY CLTB CLTS CLTE TKUL
LT GRN WIRE
MAIN BODY ECU (LEFT END OF DASH)
MEMORY SYSTEMS MEMORY SYSTEMS
NETWORK GATEWAY ECU (W/ BLIND SPOT MONITOR SYSTEM) (RIGHT SIDE OF DASH)
PNK HEAD TAIL WIRE
PNK PRG HU RCTY LSFL HF WIRE
PNK WIRE
POWER WINDOWS SYSTEM
RED WIRE
RTR RET
UL 1
VIO WIRE
WARNING SYSTEMS
WHT WIRE
YEL WIRE
Go to component -> Body ecu circuit (3 of 4) -> PNK HEAD TAIL WIRE
