Lexus ES XV60 (2012-2015) illumination light sub assembly 1) Wiring diagram
This page shows the only wiring diagram for the component.illumination light sub assembly 1), which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram illumination light sub assembly 1) (1 of 1)
+ECU
13 14 CANL CANH
22 11 PANL
23 30 ACAN BECU
32 29 31 IG
ALT FUSE
AUTO
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
D/L
ECU-B 1 FUSE
ENGINE ROOM J/B (LEFT FRONT OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HEAD
HEADLAMP DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) DOME FUSE
HOT W/
HOT W/ ACC 1 RELAY ENERGIZED
ILLUMINATION LIGHT SUB ASSEMBLY 1)
INSTRUMENT RRIL PANEL AMBIENT LIGHT (INTERIOR ILLUMINATION LIGHT SUB ASSEMBLY)
LEFT FRONT DOOR AMBIENT LIGHT (INTERIOR ILLUMINATION LIGHT SUB ASSEMBLY 1)
LEFT REAR DOOR AMBIENT LIGHT (INTERIOR ILLUMINATION LIGHT SUB ASSEMBLY 1)
LGCY
LT GRN WIRE
MAIN BODY ECU (LEFT END OF DASH)
OFF TAIL
PANEL 2 FUSE
RED WIRE
RIGHT FRONT DOOR AMBIENT LIGHT (INTERIOR
RIGHT REAR DOOR AMBIENT LIGHT (INTERIOR
TAIL
TAIL RELAY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (1 of 6) -> ILLUMINATION LIGHT SUB ASSEMBLY 1)
