Lexus ES XV60 (2012-2015) ill- operation switch ill+ Wiring diagram
This page shows the only wiring diagram for the component.ill- operation switch ill+, which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ill- operation switch ill+ (1 of 1)
ACCESSORY METER ASSEMBLY ILL-
ADIM
BLK WIRE
BLU WIRE
CLOCK ASSEMBLY
CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILL
ILL ILL
ILL- OPERATION SWITCH ILL+
LT GRN WIRE
MULTI-MEDIA MODULE DISPLAY
OUTER MIRROR SWITCH ASSEMBLY (W/ MEMORY)
OUTER MIRROR SWITCH ASSEMBLY (W/O MEMORY)
PANEL FUSE
PANEL RELAY
PNK WIRE
REMOTE +
W/ NAVIGATION
W/O NAVIGATION W/ ACCESSORY METER DISPLAY
W/O NAVIGATION W/ MULTI-MEDIA MODULE RECEIVER ASSEMBLY
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument illumination circuit (3 of 6) -> ILL- OPERATION SWITCH ILL+
