Lexus ES XV60 (2012-2015) heater mirror Wiring diagram
This page shows the only wiring diagram for the component.heater mirror, which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram heater mirror (1 of 1)
+ECU
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
DEFOGGER SYSTEM
EC MIRROR
EC+
ELECTROCHROMIC MIRROR CIRCUIT
FUSE
GRN WIRE
GRY WIRE
HEATER
HEATER MIRROR
HL VL
HOT W/ ACC 1 RELAY ENERGIZED
ILL ILL
INSTRUMENT PANEL J/B (LEFT END OF DASH)
LEFT OUTER REARVIEW MIRROR ASSEMBLY
LEFT/ RIGHT UP/ DOWN
LIGHT FOOT
LT BLU WIRE
LT GRN WIRE
MIRROR
MLP
OPERATION SWITCH
ORG/ WIRE
OUTER MIRROR SWITCH ASSEMBLY
PNK WIRE
RED WIRE
RIGHT LEFT
RIGHT OUTER REARVIEW MIRROR ASSEMBLY
SELECT SWITCH
TURN
UP DOWN
VIO WIRE
VR HR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> HEATER MIRROR
