Lexus ES XV60 (2012-2015) front outer weight detector sensor sub-assembly (right front seat adjuster) wiring diagram
This page shows the only wiring diagram for the component.front outer weight detector sensor sub-assembly (right front seat adjuster), which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front outer weight detector sensor sub-assembly (right front seat adjuster) wiring diagram (1 of 1)
16 24 FSR+ FSR-
18 10 LBE- LBE+
8 5 PNK WIRE
A/B FUSE
AIR BAG SENSOR ASSEMBLY (UNDER FRONT OF CENTER CONSOLE)
AUTO
BLK WIRE
BLU WIRE
BRAKE LEVER ASSEMBLY)
BRN WIRE
BUCKLE SWITCH
CAN I/F
CANL CANH
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
D/L
ECU-B 1 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FRONT INNER WEIGHT DETECTOR SENSOR SUB-ASSEMBLY (RIGHT FRONT SEAT ADJUSTER)
FRONT OUTER WEIGHT DETECTOR SENSOR SUB-ASSEMBLY (RIGHT FRONT SEAT ADJUSTER)
FUSE
GRN WIRE
GRY WIRE
HEADLIGHT DIMMER SWITCH ASSEMBLY
HOT AT ALL TIMES
INSTRUMENT PANEL J/B (LEFT END OF DASH)
J/C
LED DRIVER
LEFT FRONT DOOR COURTESY SWITCH
LIGHT CONTROL SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
OCCUPANT DETECTION ECU
OFF
PARKING BRAKE SWITCH (BASE OF PARKING
PNK WIRE
RED WIRE
RELAY ENERGIZED
SPEAKER
TAIL
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Seat belt warning circuit -> FRONT OUTER WEIGHT DETECTOR SENSOR SUB-ASSEMBLY (RIGHT FRONT SEAT ADJUSTER)
