Lexus ES XV60 (2012-2015) engine room j/b (left front of engine Wiring diagram
This page shows the only wiring diagram for the component.engine room j/b (left front of engine, which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine room j/b (left front of engine (1 of 1)
+ECU
13 14 19 CANL CANH LGCY
14 15 CANH CANL
ALT FUSE
BLK WIRE
BLU WIRE
CERTIFICATION ECU (RIGHT SIDE OF DASH)
COMPT)
COMPUTER DATA LINES SYSTEM
ECU-B 1 FUSE
ENGINE ROOM J/B (LEFT FRONT OF ENGINE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE
FUEL LID OPENER SWITCH
FUEL LID W/ MOTOR LOCK ASSEMBLY (FUEL FILLER DOOR)
FUEL OPN FUSE
FUSE
FUSE 29 32
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC 1 RELAY ENERGIZED
INSTRUMENT PANEL J/B (LEFT END OF DASH) FUEL OPN RELAY
LEFT "C" PILLAR)
LT GRN WIRE
LUGGAGE COMPARTMENT DOOR LOCK ASSEMBLY (CENTER REAR OF LUGGAGE COMPT LID)
LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY
LUGGAGE DOOR OPENING SWITCH ASSEMBLY
LUGGAGE ELECTRICAL KEY SWITCH
MAIN BODY ECU (LEFT END OF DASH)
RED WIRE
RELAY ENERGIZED
TMSW TSW
TRK OPN RELAY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Trunk & fuel door release circuit -> ENGINE ROOM J/B (LEFT FRONT OF ENGINE
