Lexus ES XV60 (2012-2015) drls alt Wiring diagram
This page shows the only wiring diagram for the component.drls alt, which is found in the car Lexus ES XV60 (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drls alt (1 of 1)
ALT FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONTROL LIGHT
DISPLAY DRIVER
DRL
DRLS ALT
ECU-IG 2 FUSE
ENGINE ROOM J/B (LEFT FRONT OF ENGINE COMPT)
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
FOGR
FUSE
GRN WIRE
GRY WIRE
H-LP LH LO FUSE
H-LP RELAY
H-LP RH LO FUSE
H-LP- MAIN
HID
HL HL HL HR
HOT AT ALL TIMES
INSTRUMENT PANEL J/B
INTEGRATION RELAY
J/C
LDRL FOGS IGN DIMS
LED DRIVER
LEFT FOG LIGHT ASSEMBLY
LEFT HEADLAMP ASSEMBLY
LOW (HID)
PNK PNK WIRE
PNK WIRE
RED WIRE
RELAY ENERGIZED
RIGHT FOG LIGHT ASSEMBLY
RIGHT HEADLAMP ASSEMBLY
TAIL
TELLTALES
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Headlamps circuit (2 of 2) -> DRLS ALT
