Lexus ES XV60 (2012-2015) cigarette lighter assembly Wiring diagrams
This page contains all the electrical diagrams for the component. cigarette lighter assembly, in which he is found in the car Lexus ES XV60 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cigarette lighter assembly (1 of 2)
A/C AMPLIFIER ASSEMBLY
AIR BAG SENSOR ASSEMBLY
AUTO HIGH BEAM SWITCH
AUTOMATIC LIGHT CONTROL SENSOR
BLK WIRE
CIGARETTE LIGHTER ASSEMBLY
CLOCK ASSEMBLY
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR
DOOR CONTROL SWITCH ASSEMBLY
DRIVER ALL DOOR DOOR LOCK UNLOCK RELAY RELAY
FROM GROUND
HEADLIGHT DIMMER SWITCH ASSEMBLY
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT RIGHT VISOR VISOR ASSEMBLY ASSEMBLY
MAIN BODY RELAY ECU
MULTIPLEX TILT, TELESCOPIC ECU
NCA WIRE
OPTION CONNECTOR (GLASS BREAKAGE SENSOR)
OPTION CONNECTOR (REMOTE ENGINE STARTER)
P, RR, RL DOOR UNLOCK RELAY
POWER OUTLET SOCKET ASSEMBLY
POWER OUTLET SOCKET ASSEMBLY 1
RELAY
RELAY RELAY
RIGHT FRONT DOOR LOCK ASSEMBLY
RIGHT FRONT ELECTRICAL KEY ANTENNA
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RIGHT REFRESHING SEAT SWITCH
ROOF CONSOLE BOX ASSEMBLY
SHIFT LOCK CONTROL ECU (LOWER LEFT SHIFT REFRESHING LEVER SEAT ASSEMBLY) SWITCH
SLIDING ROOF CONTROL ECU (SLIDING ROOF DRIVE GEAR SUB-ASSEMBLY)
SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN)
STEERING GLOVE BOX LOCK LIGHT ACTUATOR ASSEMBLY ASSEMBLY
STEERING SENSOR
STEERING WHEEL HEATER CONTROL ASSEMBLY STEERING HEATER
TRK ACC 1 ACC 2 OPEN RELAY RELAY RELAY
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Ground distribution circuit (3 of 6) -> CIGARETTE LIGHTER ASSEMBLY
Wiring diagram cigarette lighter assembly (2 of 2)
+ECU
A/F FUSE
AIR CONDITIONING SYSTEM
BKUP LP FUSE
BLK WIRE
BLU WIRE
BODY COMPUTER SYSTEM
BRN WIRE
CIG, P/ OUTLET FUSE
CIGARETTE LIGHTER ASSEMBLY
DOOR F/L TI, TE FUSE FUSE
DOOR FR
DOOR LOCK, ANTI-THEFT, SUPPLEMENTAL RESTRAINTS SYSTEMS
DOOR LOCKS SYSTEM
DOOR R/L
DOOR R/R
ECU-B 2 FUSE
EFI 1 FUSE
EFI- MAIN 1 FUSE
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
EXTERIOR LIGHTS INSTRUMENT SYSTEM CLUSTER, SOUND, NAVIGATION SYSTEMS
EXTERIOR LIGHTS, ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
FROM ACC 1 RELAY (DIAGRAM 4 OF 4)
FROM ACC 2 RELAY (DIAGRAM 4 OF 4)
FROM ALT-S FUSE (DIAGRAM 1 OF 4)
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 4)
FROM TAIL RELAY (DIAGRAM 4 OF 4)
FUSE
GRN WIRE
GRY WIRE
H-LP- MAIN FUSE
HEADLIGHTS SYSTEM
HORN FUSE
HORNS SYSTEM
IG 2 MAIN FUSE
INSTRUMENT PANEL J/B (LEFT END OF DASH)
MAIN BODY ECU
MAYDAY FUSE
MEMORY, MEMORY, ELECTRONIC POWER POWER WINDOWS, STEERING MIRRORS SYSTEMS SYSTEMS
MIRRORS SYSTEM
NAVIGATION SYSTEM
P/OUTLET RR FUSE
PNK WIRE
POWER OUTLET SOCKET ASSEMBLY 1
POWER OUTLET SOCKET ASSEMBLY 2
POWER WINDOWS SYSTEM
PTL FUSE
RADIO- ACC FUSE
RED WIRE
RELAY (DIAGRAM 4 OF 4)
SEATS SYSTEM
SMART FUSE
SOUND SYSTEMS
SOUND, NAVIGATION SYSTEMS
STARTING/ CHARGING SYSTEM
STOP FUSE
STRG HTR FUSE
TAIL FUSE
TO CERTIFICATION ECU (DIAGRAM 1 OF 4)
TO ENGINE ROOM J/B (DIAGRAM 3 OF 4)
TO S/ROOF FUSE (DIAGRAM 3 OF 4)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
TV FUSE
VIO WIRE
WARNING SYSTEMS POWER WINDOWS SYSTEM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> CIGARETTE LIGHTER ASSEMBLY
