Lexus ES XV60 (2012-2015) ccs cchg Wiring diagrams
This page contains all the electrical diagrams for the component. ccs cchg, in which he is found in the car Lexus ES XV60 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ccs cchg (1 of 2)
+B STP SPD
+BM
1 46 2 BATT MREL +B
10 36 SPD
13 26 54 55 56 57 58 59 CANH CANL VPA EPA VCPA
31 1 69 60 CAN+ CAN-
49 27 47 48 PNK LGND WIRE
7 6 16 17 19 18 11 4 5 14 25 2 FR+ FR- RR- RR+ FL+ FL-
ACCELERATOR POSITION SENSOR (ACCELERATOR PEDAL ASSEMBLY)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY (RIGHT SIDE OF ENGINE COMPT)
BRN WIRE
CAN (-) CAN (+)
CCS CCHG
COMPUTER DATA LINES SYSTEM
CONTROL DISTANCE
CRUISE CONTROL SWITCH CRUISE CONTROL MAIN SWITCH
EFI 1 FUSE
EFI 2 FUSE
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ETCS FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
INTEGRATION RELAY
LEFT REAR SPEED SENSOR (LEFT REAR HUB ASSEMBLY)
LT GRN WIRE
M+ M- VCTA
MAIN
MODE
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT STEERING PAD SWITCH
RL- RL+ CANL CANH STP
SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN)
STEERING PAD SWITCH
STPS
THROTTLE BODY W/ MOTOR (INTAKE MANIFOLD)
TRANSMISSION CONTROL ECU ASSEMBLY (LEFT SIDE OF TRANSMISSION)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit, with dynamic radar controls (1 of 2) -> CCS CCHG
Wiring diagram ccs cchg (2 of 2)
+B STP SPD
+BM
1 46 2 BATT MREL +B
10 36 SPD
13 26 54 55 56 57 58 59 CANH CANL VPA EPA VCPA
31 1 69 60 CAN+ CAN-
7 6 16 17 19 18 11 4 5 14 25 2 FR+ FR- RR- RR+ FL+ FL-
ACCELERATOR POSITION SENSOR (ACCELERATOR PEDAL ASSEMBLY)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY (RIGHT SIDE OF ENGINE COMPT)
BRN WIRE
CAN (-) CAN (+)
CCS CCHG
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH CRUISE CONTROL MAIN SWITCH
EFI 1 FUSE
EFI 2 FUSE
EFI MAIN FUSE
EFI MAIN RELAY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
ETCS FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
INTEGRATION RELAY
LEFT REAR SPEED SENSOR (LEFT REAR HUB ASSEMBLY)
LT GRN WIRE
M+ M- VCTA
MAIN
MODE
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RL- RL+ CANL CANH STP
SPIRAL CABLE SUB-ASSEMBLY (STEERING COLUMN)
STPS
THROTTLE BODY W/ MOTOR (INTAKE MANIFOLD)
TRANSMISSION CONTROL ECU ASSEMBLY (LEFT SIDE OF TRANSMISSION)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit, without dynamic radar controls (1 of 2) -> CCS CCHG
