Lexus ES XV60 (2012-2015) blk Wiring diagrams

This page contains all the electrical diagrams for the component. blk, in which he is found in the car Lexus ES XV60 (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram blk (101 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (101 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

15 SPEAKER RIGHT FRONT SPEAKER ASSEMBLY 2 18 16 19 MCO+ MACC MCO- 2 3 17 SPI+ SPI- MUTE 3 5 6 7 2 4 1 VOT+ VOT- VOR- VOR+ USBG USBV USB 32 35 33 34 PNK SGND MCI- MCVD MCI+ WIRE 5 6 7 8 9 10 11 12 PNK WIRE BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY (RIGHT SIDE OF ENGINE COMPT) BRN WIRE CAN I/F CB+ CGND COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM CURT CV+ DCM (TELEMATICS TRANSCEIVER) (W/ LEXUS ENFORM) (UNDER FRONT PASSENGER'S SEAT) GRN WIRE GRY WIRE J/C LEFT FRONT SPEAKER ASSEMBLY 1 LT GRN WIRE MACC MCO- PNK WIRE RED WIRE RIGHT FRONT SPEAKER ASSEMBLY 1 ROOF CONSOLE BOX ASSEMBLY SHIELD STEREO COMPONENT SPEAKER ASSEMBLY USB USBG USBV VIO WIRE VOR- VOT+ W/ BACK GUIDE MONITOR W/ LEXUS ENFORM W/O LEXUS ENFORM WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, with navigation (2 of 3) -> BLK WIRE

Wiring diagram blk (102 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (102 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

1 14 PNK WIRE 1 2 3 4 5 6 7 8 WUO MI+ MI- SLDI MO+ MO- SLDO 15 SPEAKER FRONT SPEAKER ASSEMBLY 3 15 SPEAKER LEFT FRONT SPEAKER ASSEMBLY 2 3 1 2 4 +TW -TW AMP 2 FUSE AMP FUSE BLK WIRE BLU WIRE BRN WIRE CTR + ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR HEADER SPEAKER ASSEMBLY (15 SPEAKER) LEFT REAR SPEAKER ASSEMBLY LEFT REAR SPEAKER ASSEMBLY 2 LT GRN WIRE MI+ MI- SLDI MO+ MO- SLDO WUI MULTI-MEDIA MODULE RECEIVER (CENTER OF DASH) NCA WIRE PNK WIRE RED WIRE RIGHT REAR HEADER SPEAKER ASSEMBLY (15 SPEAKER) RIGHT REAR SPEAKER ASSEMBLY RIGHT REAR SPEAKER ASSEMBLY 2 SHIELD SHIELD AGND SL- SR- FL- FR- RL- RR- STEREO COMPONENT AMPLIFIER (UNDER DRIVER'S SEAT) STEREO JACK ADAPTER ASSEMBLY 1 VA- ADPG VAR+ VAL+ VIO WIRE W/ 15 SPEAKER W/ 8 SPEAKER WFL- WFR- WHT WIRE YEL WIRE

Go to component -> Radio circuit, with navigation (3 of 3) -> BLK WIRE

Wiring diagram blk (103 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (103 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

3 1 2 PNK WIRE BLK WIRE BLU WIRE EAU FUSE GRN WIRE GRY WIRE HOT W/ ACC 2 RELAY ENERGIZED INSTRUMENT PANEL J/B (LEFT END OF DASH) IVO+ IVO- LEFT STEERING PAD SWITCH MIN+ MACC MIN- SGND PNK WIRE MODE NCA WIRE OFF HOOK ON HOOK PNK WIRE RADIO RADIO RECEIVER ASSEMBLY RED WIRE RIGHT STEERING PAD SWITCH SEEK SHIELD SPIRAL CABLE (STEERING COLUMN) STEERING PAD SWITCH ASSEMBLY STEREO JACK ADAPTER ASSEMBLY 1 SWG TXM- TXM+ VAR+ VA- VAL+ AGND ADPG VIO WIRE VOICE VOICE RETURN VOLUME- WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without navigation & multi-media module receiver assembly (1 of 3) -> BLK WIRE

Wiring diagram blk (104 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (104 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

18 16 19 MCO+ MACC MCO- 2 3 17 SPI+ SPI- MUTE 32 35 33 34 PNK SGND MCI- MCVD MCI+ WIRE BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY (RIGHT SIDE OF ENGINE COMPT) BRN WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DCM (TELEMATICS TRANSCEIVER) (W/ SAFETY CONNECT) (UNDER FRONT PASSENGER'S SEAT) ECU-B 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (LEFT END OF DASH) J/C MACC MCO- PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT SPEAKER ASSEMBLY 2 ROOF CONSOLE BOX ASSEMBLY SHIELD VIO WIRE W/ SAFETY CONNECT W/O SAFETY CONNECT WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without navigation & multi-media module receiver assembly (2 of 3) -> BLK WIRE

Wiring diagram blk (105 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (105 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 MUTE L- L+ R- R+ 15 16 ATX- 5 6 7 8 ATX+ AMP 2 FUSE AMP FUSE BLK WIRE BLU WIRE BRN WIRE CTR + ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF FL- FR- RL- RR- FRONT SPEAKER ASSEMBLY 3 GND WFL+ WFR+ GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 2 LEFT REAR SPEAKER ASSEMBLY LT GRN WIRE MUTE R+ L+ SLD PNK WIRE R- L- GND RADIO RECEIVER ASSEMBLY RED WIRE RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT REAR SPEAKER ASSEMBLY SHELD STEREO COMPONENT AMPLIFIER (UNDER DRIVER'S SEAT) STEREO COMPONENT SPEAKER ASSEMBLY TMUT TV FUSE TX- TX+ VIO WIRE WFL- WFR- WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without navigation & multi-media module receiver assembly (3 of 3) -> BLK WIRE

Wiring diagram blk (106 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (106 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 IG 4 8 1 3 6 7 TX+ TX- ADPG VAR+ VA- VAL+ ASSEMBLY) PARKING BRAKE SWITCH BLK WIRE BLU WIRE CANH CANL AGND CB+ CGND COMPUTER DATA LINES SYSTEM CV+ EAU FUSE GND ILL+ ILL- GRN WIRE GRY WIRE GVIF HOT W/ ACC 2 RELAY ENERGIZED INSTRUMENT PANEL J/B LEFT STEERING PAD SWITCH STEERING PAD SWITCH ASSEMBLY MACC MIN+ MODE SEEK- MULTI-MEDIA MODULE DISPLAY MULTI-MEDIA MODULE RECEIVER (CENTER OF DASH) NCA WIRE OFF HOOK ON HOOK ORG/ WIRE PNK 1 2 3 WIRE PNK WIRE RADIO RED WIRE RELAY ENERGIZED REMOTE OPERATION SWITCH RIGHT STEERING PAD SWITCH SEEK SHIELD SHIELD CGND V- SPD SGND MIN- PNK WIRE SPIRAL CABLE (STEERING COLUMN) STEREO JACK ADAPTER ASSEMBLY 1 SWG VIO WIRE VMTF PKB CA+ V+ VMTI VOICE VOICE RETURN VOLUME- WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without navigation & with multi-media module receiver assembly (1 of 3) -> BLK WIRE

Wiring diagram blk (107 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (107 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

18 16 19 MCO+ MACC MCO- 2 3 17 SPI+ SPI- MUTE 32 35 33 34 PNK SGND MCI- MCVD MCI+ WIRE BLK WIRE BLU WIRE BRAKE ACTUATOR ASSEMBLY (RIGHT SIDE OF ENGINE COMPT) BRN WIRE CAN I/F COMBINATION METER ASSEMBLY COMPUTER DATA LINES SYSTEM DCM (TELEMATICS TRANSCEIVER) (W/ SAFETY CONNECT) (UNDER FRONT PASSENGER'S SEAT) ECU-B 1 FUSE ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL J/B (LEFT END OF DASH) J/C MACC MCO- PNK WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT SPEAKER ASSEMBLY 2 ROOF CONSOLE BOX ASSEMBLY SHIELD VIO WIRE W/ SAFETY CONNECT W/O SAFETY CONNECT WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without navigation & with multi-media module receiver assembly (2 of 3) -> BLK WIRE

Wiring diagram blk (108 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (108 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 MUTE L- L+ R- R+ AMP 2 FUSE AMP FUSE BLK WIRE BLU WIRE BRN WIRE CTR + ENGINE COMPT) ENGINE ROOM R/B (LEFT SIDE OF FL- FR- RL- RR- FRONT SPEAKER ASSEMBLY 3 GND WFL+ WFR+ GRN WIRE GRY WIRE HOT AT ALL TIMES IVO+ IVO- 17 18 19 20 LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 2 LEFT REAR SPEAKER ASSEMBLY LT GRN WIRE MULTI-MEDIA MODULE RECEIVER (CENTER OF DASH) PNK WIRE R - L - R+ L+ SLD RED WIRE RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT REAR SPEAKER ASSEMBLY SHIELD SHIELD 15 16 STEREO COMPONENT AMPLIFIER (UNDER DRIVER'S SEAT) STEREO COMPONENT SPEAKER ASSEMBLY TMUT TV FUSE TX- TX+ VIO WIRE WFL- WFR- WHT WIRE WHT/BLK WIRE YEL WIRE

Go to component -> Radio circuit, without navigation & with multi-media module receiver assembly (3 of 3) -> BLK WIRE

Wiring diagram blk (109 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (109 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

BKUP LP FUSE BLK WIRE BLU WIRE CANL CANH CERTIFICATION CANH ECU (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM ECM (ENGINE CONTROL MODULE) (LEFT SIDE OF ENGINE COMPT) FUSE GRN WIRE HOT AT ALL TIMES HOT W/ INSTRUMENT PANEL J/B (LEFT END OF DASH) P POSITION DETECTION SWITCH PARK/NEUTRAL POSITION SWITCH (TRANSMISSION ASSEMBLY) RED WIRE RELAY ENERGIZED SHIFT LOCK CONTROL ECU (UNDER CENTER CONSOLE) SHIFT LOCK SOLENOID STOP FUSE STOP LIGHT SWITCH STP IG VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Shift interlock circuit -> BLK WIRE

Wiring diagram blk (110 of 144)

Wiring diagram blk for Lexus ES XV60 (2012-2015) (110 of 144)
Get lifetime access to Lexus ES XV60 (2012-2015)

BLK WIRE BLU WIRE CERTIFICATION ECU (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM ENGINE ROOM J/B (LEFT FRONT OF ENGINE COMPT) FUSE HOT AT ALL TIMES HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT) ID CODE BOX (LEFT SIDE OF DASH) LIN LIN 1 LIN PNK 3 2 IGE WIRE LT GRN WIRE PNK WIRE RELAY ENERGIZED SL/R SLP STEERING LOCK ACTUATOR (STEERING COLUMN) STRG LOCK FUSE VIO WIRE WHT WIRE WHT/BLK WIRE

Go to component -> Steering column circuit -> BLK WIRE
