Electrochromic mirror circuit for Lexus ES XV40 facelift (2009-2012)
Electrochromic mirror circuit
1 2 3 4 5 PNK EC- EC+ IG WIRE
BLK WIRE
BLU WIRE
BRN WIRE
ECU- IG 1 FUSE
INNER REAR VIEW MIRROR
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LEFT OUTER REAR VIEW MIRROR
LT GRN WIRE
OVERHEAD J/B (CENTER FRONT OF ROOF)
PNK WIRE
RELAY ENERGIZED
RIGHT OUTER REAR VIEW MIRROR
WHT/BLK WIRE
