Rear defogger & heated mirrors circuit for Lexus ES XV40 facelift (2009-2012)
Rear defogger & heated mirrors circuit
A/C 2 FUSE
A/C AMPLIFIER (RIGHT SIDE OF DASH)
BLK WIRE
BRN WIRE
FUSE
GRN WIRE
HOT AT ALL TIMES ENGINE ROOM R/B (LEFT SIDE OF ENGINE RR DEF FUSE COMPT)
HOT IN ON OR START
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LEFT OUTER REAR VIEW MIRROR
MIR HTR
MIRROR HEATER
NOISE FILTER (REAR WINDOW DEFOGGER) (NEAR LEFT ``C" PILLAR)
PNK WIRE
REAR WINDOW DEFOGGER
REAR WINDOW RDFG DEFOGGER SWITCH
RED WIRE
RIGHT OUTER REAR VIEW MIRROR HEATER MIRROR
RR DEF RELAY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
