Lexus ES XV40 facelift (2009-2012) ts canl computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.ts canl computer data lines system, which is found in the car Lexus ES XV40 facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ts canl computer data lines system (1 of 1)
ABS 1 FUSE
BLK WIRE
BLU WIRE
BRN WIRE
BZ +BS GND 1
COMPUTER DATA CANH LINES SYSTEM
COMPUTER DATA D/G MRF MR STPO FR- FL+ RR- RL+ STP 2 LINES SYSTEM
COMPUTER DATA LINES SYSTEM
COMPUTER DATA WFSE LINES SYSTEM
ECU-IG 2 FUSE
ENGINE ROOM R/B (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILL ILL
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
JUNCTION CONNECTOR
LEFT FRONT SPEED SENSOR (LEFT FRONT HUB ASSEMBLY)
LEFT REAR SPEED SENSOR (LEFT REAR HUB ASSEMBLY)
LT GRN WIRE
ORG/ WIRE
PNK 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 STP 1 PNK WIRE
PNK 4 5 WIRE
PNK WIRE
R+ PNK WIRE
RED WIRE
RED/BLU WIRE
RIGHT FRONT SPEED SENSOR (RIGHT FRONT HUB ASSEMBLY)
RIGHT REAR SPEED SENSOR (RIGHT REAR HUB ASSEMBLY)
SKID CONTROL ECU W/ ACTUATOR (RIGHT FRONT OF ENGINE COMPT)
STOP FUSE
TS CANL COMPUTER DATA LINES SYSTEM
VIO WIRE
VSC OFF SWITCH
VSC RELAY 1
VSC RELAY 2
VSC WARNING BUZZER (IF EQUIPPED) (NEAR CENTER OF DASH)
W/ DYNAMIC RADAR CRUISE CONTROL W/O DYNAMIC RADAR CRUISE CONTROL
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> TS CANL COMPUTER DATA LINES SYSTEM
